Cutting & Fold-bend Machine

Full Automatic Tube Bender

Zhangjiagang King-Macc Machinery Manufacturing Co., Ltd.
  • Waterproof Rating:IPX-8
  • Warranty:2-year
  • Condition:New
  • Certification:ISO 9001:2000, CE, UL
  • Automation:Automatic
  • Suitable for:Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel

Base Info

  • Model NO.:GM-SB-114NCBA
  • Type:Pipe and Tube Bending Machine
  • Certificate:ISO9001: 2000
  • Applicable Material:S. S, M. S., Copper, Aluminium, Alloy, Galvanized
  • Applicable Shape:Round, Rectangle, Square, Oval, Solid Bar, Profile
  • Bending Drive:Hydraulic
  • Technical:Cold Bend
  • Transport Package:Iron Frame,Wooden Case
  • Specification:CE
  • Trademark:GMACC
  • Origin:China
  • HS Code:8462219000
  • Production Capacity:5000PCS,Year


Basic Info.

Model NO. GM-SB-114NCBA Type Pipe and Tube Bending Machine Certificate ISO9001: 2000 Applicable Material S. S, M. S., Copper, Aluminium, Alloy, Galvanized Applicable Shape Round, Rectangle, Square, Oval, Solid Bar, Profile Bending Drive Hydraulic Technical Cold Bend Transport Package Iron Frame/Wooden Case Specification CE Trademark GMACC Origin China HS Code 8462219000 Production Capacity 5000PCS/Year

Product Description

1. Automatic Rotating
2. Bending Capability: OD10-325mm
3. PLC, Servo Motor: Mitsubishi/Delta
4. High Accuracy/stability

The series was adapted in particular to professional world market requirements. All the parts, structure and characters are similar to the standard of mechanical engineering from Europe. Our professional experience and drawings plans for Electric, Electronic, Hydraulic and mechanical from known companies bring to upgrading of the machines' systems to accurate and attractive performance.

GM-SB-NCBA series single-head bending machine, importing advanced design technology from Italy, is a kind of automatic three-dimensional pipe bending machine, integrated with machine, hydraulic, and electricity. Various data and orders can be input and stored in advanced imported touch screen, which can automatically rotate the angle in three dimension continuously, besides, manual material feeding meets the requirement for processing precision of complicated work pieces all make NC series a professional and high speed European pipe bending equipment.

1. Applicable tube material: Carbons steel, mild steel, soft steel, stainless steel, aluminum, alloy, copper, brass etc.
2. Applicable tube shape: Tube, solid bar, square, rectangle, oval, profile etc
3. Controlled through PLC and possesses manual, semi-automatic and full-automatic functions.
4. Servo motor controlled rotating ensures the three-dimensional bending and efficiency working.
5. Equipped with hydraulic-operated clamping tube, encoder-controlled bending angle with precision more or less 0.1 degree.

6. About 200 programs can be inputted into PLC, then show on dialogue-style operation touch screen, easy to learn and understand.
7. Various Touch screen language are available for choice as per request.
8. Adoption of hydraulic valve and oil way board can control actions individually to prolong the lifespan of hydraulic parts.
9. Guiding module has auxiliary pushing function and at the same time it possesses reiteration and entering repeat functions that can make the guiding module length shorten.
10. Counter function can accurately count work piece's quantity and save data whether in power-on or power-off situation.

11. Auto lubrication system to protect components and improve the working life of machine;
12. Possess automatic error detection function and limit protecting function, removing or changing faults easily and quickly.
13. Moveable foot switch with function of auto-start, pause and emergent-shop, safe and convenient.
14. Optional function of core reversing slowly.
15. Optional function of slow bending.
16. Optional function of anticipated mandrel extraction.
NameUnit  Parameter
Max. Bending Capacitymm114*8
Bending Radius Rangemm40-500
Max. Bending Angle°190°
Though Effective Distancemm3200
Bending speed° /sec20
Turning speed° /sec160
Bending precision°± 0.10
Turning precision°± 0.10
Rotating Servomotor PowerKW3
System Motor PowerKW15
Oil Pump Delivery VolumeL36
Max. PressureMpa16
L*W*H (Packaging Dimension)mm6500*1350*1300
Configuration of Hydraulic and Electronic Control System
Hydraulic MotorSuzhou Jialifan
Hydraulic PumpWuxi Tuoli
Hydraulic ValveJapan Yuken(Imported)
Oil way BoardTaiwan Shanghong (Imported)
CylinderShanghai Qifan
Oil tubeTaiwan TATUNG(Imported)
Touch screenTaiwan Weinview
PLCJapan Mitsubishi(Imported)
Angle controllerJapan Nemicon
Switch powerTaiwan Mean Well(Imported)
ContactorTaiwan SHIHLIN(Imported)
Other Electric PartsGerman SCHNEIDER, Omron, Taiwan SHILIN(Imported)

Full Automatic Tube Bender
Full Automatic Tube Bender
Full Automatic Tube Bender
