• Model NO.：LJZ2SA-500x5000
• Specification：CE
• Trademark：Tianchen
• Origin：Jinan, Shandong Province
• HS Code：84614090
• Production Capacity：2000 Sets,Year

Basic Info.

Model NO. LJZ2SA-500x5000 Specification CE Trademark Tianchen Origin Jinan, Shandong Province HS Code 84614090 Production Capacity 2000 Sets/Year

Product Description

Equipment features

1. This is one new designed machine which used for cutting profile of aluminum door and windows, curtain wall and corner connector.
2. It has feature of easy operation, reliable performance, advanced technique and convenient maintenance, etc.
3. It adopts imported OMRON control systems from Japan, with high accuracy and stability.
4. The profile cutting size adopts the digital display technique to ensure high efficiency and accuracy.
5. Imported carbide saw blade gives accurate processing and high efficiency.
6. Two head can work together or single, when together work, one time can cut off the required length and angle

Main specification and technical parameter
Power supply	380V 50Hz
Saw-head motor power	2×2.2 KW
Rotary speed	2800r/min
Operation air pressure	0.5MPa-0.8Mpa
Cutting length	Max.4200mm   Min.400mm
Air consumption	60L/min
Cutting width	Max. 135mm
Cutting height	900:max. 300mm   450:max. 200mm
Cutting angle	90°45°67.5°(spare)
Cutting speed	stepless speed regulation   0-3m/min
Blade specification	500mm×4.4mm×30mm Z=120
Repeat locating length allowance	±0.2mm
Cutting profile surface plane	≤0.10mm
Cutting angle allowance	±5'
Cutting profile surface roughness	Ra12.5um
Contour dimension	5560mm×1750mm×1950mm
Weight	About 1800kg
