Pipe Bending Machine/Single Head Pipe Bending Machine

Zhangjiagang Caos Precision Machinery Manufacturing Co., Ltd.
  • Certification：ISO 9001:2008, CE
  • Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
  • Model：Sb38nc
  • Max Bending Radiu：200mm
  • Min Bending Radiu：20mm
  • Max Wear Core：1700mm

Base Info

  • Model NO.：SB38NC
  • Max Bending Angle：185
  • Bend Pipe Fittings Can Be Set：2,9
  • Max Hydraulic Pressure：12MPa
  • Machine Size：2700*600*1250
  • Weight：900kg
  • Transport Package：Wood
  • Specification：SB38NC
  • Trademark：CAOS
  • Origin：China
  • Production Capacity：100set,Per Year

Description


Specification/ModelUnitSB38NCRemarkMax bending capabilitymmΦ38×2
1. The Minimum bending diameter based onthe pipe diameter
2.The Max bending diameter can accordingto the customers requirement
3.The Max length of mandrel can according to customers requirement
Max bending radiusmmR200Min bending radiusmmR20Max bending angleDegree185Max effective distance of mandrelmm1700Control System NC ControlMax elbow bend pipeUnit16Max storable sectionsUnit16×16Motor powerKW4Max. Hydraulic PressureMpa12Hydraulic System Control Electromagnetic ValveOil Tank CapacityL110Measurementmm2700×600×1250Weight of MachineKg900
