Hydraulic Powered 12mm Metal Plate Cutting Machine
Shanghai YingXin World Machinery Co., Ltd.- After-sales Service:Available
- Certification:CE, ISO 9001:2000
- Condition:New
- Warranty:1 Year
- 12mm Plate Cutting Machine:Hydraulic Shearing Machine
- Cutting Thickness:12mm Maximum
Base Info
- Model NO.:QC11Y
- Transport Package:in Container
- Specification:CE
- Trademark:WORLD
- Origin:Jiangsu
- HS Code:84629960
- Production Capacity:2000PCS,Year
Description
Basic Info.
Model NO. QC11Y Transport Package in Container Specification CE Trademark WORLD Origin Jiangsu HS Code 84629960 Production Capacity 2000PCS/YearProduct Description
sheet metal cutting machine hydraulic plate shearFeatures:
1)Entirely steel welded frame, treated to release stress by tempering.
2)Hydraulic drive, return of knife beam is smooth and prompt by nitrogen cylinder.
3)Adopts rolling guideway to raise shear precision.
4)The stroke of knife beam can be adjusted.
5)With counter.
6)Shearing angle can be adjusted.
7)With protection fence.
Specifications
Items | unit | QC11Y-6x2500 | QC11Y-6x3200 | QC11Y-6x4000 |
Max. cutting thickness | mm | 6 | 6 | 6 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
Travel distance of back gauge | mm | 20-550 | 20-550 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 16-26 | 12-22 | 10-20 |
Main motor | kW | 7.5 | 7.5 | 7.5 |
Length | mm | 3000 | 3700 | 4800 |
Width | mm | 1500 | 1650 | 1650 |
Height | mm | 2000 | 2050 | 2250 |
Items | unit | QC11Y-8x2500 | QC11Y-8x3200 | QC11Y-8x4000 |
Max. cutting thickness | mm | 8 | 8 | 8 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-2 | 0.5-2 | 0.5-2 |
Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 14-25 | 12-20 | 10-20 |
Main motor | kW | 11 | 11 | 11 |
Length | mm | 3040 | 3860 | 4800 |
Width | mm | 1700 | 1700 | 1800 |
Height | mm | 2150 | 2350 | 2480 |
Items | unit | QC11Y-10x2500 | QC11Y-10x3200 | QC11Y-10x4000 |
Max. cutting thickness | mm | 10 | 10 | 10 |
Max. cutting width | mm | 2500 | 3200 | 4000 |
Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
Throat depth | mm | 150 | 150 | 150 |
Stroke speeds | spm | 12-20 | 10-20 | 10-18 |
Main motor | kW | 11 | 15 | 15 |
Length | mm | 3040 | 3860 | 4800 |
Width | mm | 1700 | 1700 | 1800 |
Height | mm | 2150 | 2350 | 2480 |
