Dw50CNC2a-1s 2 Motors 1 Layer Bar Bending Machine
Zhangjiagang Baorui Machinery Co., Ltd.- Warranty:1 Year, 1 Years
- Condition:New
- Certification:CE
- Automation:Automatic
- Weight (Kg):2500
- Keyword:Pipe Bending Machine
Base Info
- Model NO.:DW50CNC2A-1S
- Model:Dw50CNC2a-1s
- Material:Stainess Steel
- Machine Weight:2500kg
- Key Selling Points:High Productivity
- After Warranty Service:Video Technical Support
- Usage:Metal Sheet Rolling Cutting Bending
- Machine Size:5000*1300*1500Tmm
- Color:Blue
- Bending Precision (Deg):±0.1
- Max. Bending Angle (Deg):190
- Application:Round Pipe Bending
- Product Name:Dw50CNC2a-1s 2 Motors 1 Layer Pipe Bending Machine
- Power (Kw):5.5
- Trademark:baorui
- Origin:Jiangsu, China
Description
Item
Name
Unit
Data
Remark
1
Max bending capacity
square tube
35 X 35 X 2mm
2
Max bending radius
mm
250
Can according to customer's requirement
3
Min bending radius
mm
Depend on diameter
4
Max feeding length
Mandrel length
mm
3000
Can according to customer's requirement
5
Max bending degree
Degree
190
6
Control Panel
PLC+touch screen
7
Bending unit
piece
16
8
Working speed
bending speed
Deg/sec
85
Rotary speed
Deg/sec
200
Feeding speed
mm/sec
1000
9
Accuracy
feeding
mm
±0.1
rotary
Degree
±0.1
bending
Degree
±0.1
10
Rotary servo motor power
W
750
Japan Mitsubishi
11
Feeding servo motor power
Kw
1
Japan Mitsubishi
12
The accuracy of roller
mm
Max 70
Can according to customer's requirement
13
Oil motor power
Kw
5.5
14
Max storage units
group
2000000
Can enlarge according to requirement
15
Max pressure
MPa
12
Adjustable
16
Hydraulic control system
Magnetic exchange valve
Japan Yuken
17
Oil tank
L
190
Feel free to contact us 24 hours online
Accessories
1.1 sets of tooling
2.tool box : 1 pcs
3.Operation manual : I sets in English
After sales service.
1.Our guarantee time is one year, if any component is damaged during guarantee time,
we can send the component to the customer by DHL, TNT freely.
2.Our factory can send our engineer to the customer's factory install, commission and training freely.
The customer provide the double trip tickets, food and accommodation for our engineer.
The customer also can send the engineer to our factory to learn the operation and maintains freely.
3.Our factory provide the service for the customer forever, if the customer need operation help,
can contact us by WhatsApp, Skype, Email and Telephone at any time, we provide 24 hours on-line service.
Our factory also will make videos to show the operation steps for the customer.
