• Model NO.：zyb-63t*2500
• Connector：Germany Emb
• Main Motor：Siemens
• Electrics：Schneider
• Seal Ring：Nok
• Pump：Rexroth
• Toolings：Lianmeng
• Ball Screw：Hiwin
• Transport Package：Plastic Cover
• Specification：CE
• Trademark：ZYMT
• Origin：China
• HS Code：8462299000
• Production Capacity：3000sets,Year

Model
(ZYB-)63T
/2500100T
/3200125T
/3200160T
/3200200T
/3200250T
/3200300T
/320400T
/4000500T
/6000600T
/6000800T
/6000800T
/80001000T
/60001000T
/80001000T
/1000Nominal force(KN)63010001250160020002500300040005000600080008000100001000010000Bending length(mm)2500320032003200320032003200400050006000600080006000800010000Vertical distance(mm)190027002700270027002700270035004900490049005900490069008000Throat depth(mm)350400400400400400400400500500600600600600600Stroke (mm)170200200200200200200320320320400400400400400Max. opening(mm)380420420420420420420420600600600600600600600Main power(KN)5.57.5111115152230374555552*372*372*37Axes3+1(Y1,Y2,X,V)CompensationHydraulic compensationMotorized compensationX-travel(mm)500800X-speed200mm/sOverall length(mm)3100350035003500350035003500450065006500650085006500850010500Overall width(mm)145015801580165016801700180024502810291029502950300030003000Overall height(mm)205024002400250025502600273035004500510053005900560061005850Approximate weight(ton)5.88.59.5111415.516.831536890120100130150


Main components of ZYB model Hydraulic Press Brake:
(Standard)
1. Control System: DELEM DA52S
2. Servo motor and drive: Estun China
3. Hydraulic System: HOERBGER /
BOSCH Germany
4. Ball bearing lead screw:
Taiwan HIWIN
5. Straight-line guide:
Taiwan HIWIN
6. Connector: Germany EMB
7. Seal ring: Germany FIETZ or
Japanese VALQUA
8. Raster Ruler: Heidemhain Germany
9. Main electrical elements:
TE/OMROM/SIEMENS
10. Standard axes: Y 1 , Y 2 , X and V( V
for crowing table)

Optional of Hydraulic Press Brake:
1. DELEM DA56
2. DELEM DA66T
3. R/Z1/Z2-axis
4. Laser beam
5. Light beam



Packing&Delivery:
With more than 10 years exporting experience, we are so skilled for loading containers and packing the machines in container for safety. Each machine use min. 6mm dimeter steel rope to fix the four angles with the container, to avoid the machinery equipment move in the container.

Our Services:

1.24 hours telephone line is available for any question.

2.Experienced service technician team is available.

3.Support in hard work solution.
