Portable Cg2-600 Automatic Cutting Machine for Circle Cut
SHANGHAI CHD WELDING & CUTTING EQUIPMENT CO., LTD.- Certification：ISO 9001:2015
- Condition：New
- Control：Semi-Automatic
- Application：Metal
- Connected Shaft Number：2-Shaft
- Style：Desktop
Base Info
- Model NO.：CG2-600
- Type：Gas Cutting
- Customized：Customized
- Layout：Coaxial
- Cutting Material：Carbon Steel, Iron, Stainless Steel
- Automatic Grade：Semi-Automatic
- Power Source：Electric
- Cutting Mode：Gas Cutting
- Weight：53kg
- Speed Adjust：SCR Control
- Input Voltage：AC220V,50Hz
- Cutting Thickness：5-50mm
- Cutting Diameter：30-600mm
- Torch Speed：0.2-6rpm
- with Parts：Round Holes, Flange etc.
- Gas Distributor：Have
- Rollers Under Body：Have
- Transport Package：CTN
- Specification：750*300*700mm
- Trademark：ZHENGTE
- Origin：Shanghai
- HS Code：8456909000
- Production Capacity：20000pieces,Year
Description
Features of Zhengte Portable Cg2-600 automatic Cutting Machine for Circle Cut1 Adopt SCR control adjust Speed mechanical polarization variable speed, steady speed; 2 With rollers under the body bottom, easy to move 3 Adopt rotating gas distributor, hose is not winding when work; 4 Professional for cutting round parts, round hole, flange, etc.; Input voltage : AC220V/50Hz 5 Cutting thickness: 5-50mm 6 Cutting diameter: φ30-φ600mm 7 Torch speed :0.2-6rpm 8 Weight:53kg
C,Main structure brief introduction
1. transmission system: By ZYT-261 the direct-current rare earth magnetoelectric machine, decelerate the worm
bearing adjuster and 3 group of reduction gears through one pair is composed
2. machine body: The entire organism uses the high-test cast iron, the lutetium alloy casting and many seamless
steel pipe compositions.
3. cutting torch and cutting nozzle: Uses the equi-pressure type cutting torch, cutting nozzle uses GO2 1#-3#,
the cutting torch to be possible to reciprocate through the gear. When cuts the bevel, the cutting torch rotatable
becomes the corresponding angle.
4. Electric appliance control system: This mechanical and electrical control series by the electric appliance box,
the electrical machinery two parts is composed, the electric appliance box surface is loaded with the velocity
modulation potentiometer knob, the reversing stops the switch, in the electric appliance box is loaded with the
power transformer, the control wiring board.
Match Nozzle Type and Cutting Thickness generally we carry three cutting torches in the packing list (1#2#3#)Nozzle No.Cutting thickness Oxygen pressure Acetylene
pressure Cutting speed MPa MPa mm/min 00 5~10 0.20~0.30 >0.03 600~450 0 10~20 480~380 1 20~30 0.25~0.35 400~320 2 30~50 350~280 3 50~70 0.3~0.4 >0.01 300~240 4 70~90 260 5 90~120 0.4~0.5 200~170
FAQ:
1. Q: Certificate
A: ISO, CE, SGS, CCC
2. Q: Cutting Thickness Range ?
A: 5-50 MM
3. Q: Cutting Circle's diameter Range?
A: 30-600 MM
4. Q: Cutting material?
A: iron, steel,
5. Q: Lead Time, Delivery Time
A: 7 working days
6. Q: Warranty
A: 1 Year
7. Q: After service
A: 24 Hours Online Service, Free spare parts for breakdown machine in warranty service
8. Q: Portable or not?
A: Yes
Or you can tell me the following info, we'll suggest you the very item you need.
1. Material you'll cut.
2. Thickness of Material.
3. Cutting range (Length, width) you required.
4. Handheld torch or automated machine you required?
CHD WELDING
CHD was founded in 1989, is a High-Tech Enterprise which integrates R&D, Production, Sales and Service of cutting machine.
CHD, as one of the largest metal cutting machine manufacturers, headquartered in Shanghai, China. With 3 production bases, totally plant area of more than 53,000 square meters , respectively located in Shanghai, Chengdu and Wenzhou.
CHD focus on quality control, has passed many certification audits including ISO9000, SGS, CE, CCC, etc., was one of the world's largest manufacturer's partners of steel plate cutting equipment. CHD cutting machines have already been exported to more than 100 countries in the past 20 years.
Advantages of CHD
1. Large Production Capacity.16 R& D stuff, 120 Workers, 3 Production Bases,Plant of 53000 Square Meters. 10 Production Lines.
2. Full line of Products. Cutting Machine, Plasma Power, Welding Machine, Beveling Machine, Circular Cooling Water Tanks, Consumables.
3. Honesty. All parameters (cutting thickness & precision) are actual operation parameters without overstate.
4. Good after service, not one-off business.
5. One year guarantee. Free spare parts service on base of order amount. Engineer oversea service.
6. Adjustable Short Lead Time.
7. Quality been assurance. We are OEM supplier of one of world's largest cutting machine company. Most of our products have CE and CCC certificate.
