Steel Plate Bending Machine
Shining Industrial Enterprise (China) Co., Ltd.- Condition：New
- Certification：CE
- Automation：Semi-Automatic
- Transport Package：Steel Pallet Packaged
- Specification：Two Standard Components(CE& INT′L Standard)
- Trademark：SIECCTECH,SIECC
Base Info
- Model NO.：WC67Y 125TONX3200 HYDRAULIC BENDING MACHINE
- HS Code：8462109000
- Production Capacity：250 Set Per Month
Description
Nominal Force of the Ram1250KNS Table Length 3200MM Working Table Width 200MM Upright Colum Distance 2600MM Throat Depgh 320MM Max. Stroke Of the Ram 100MM Max. Open Height Between the table and Ram 380MM Max.stroke of block 100MM Speed for the Ram Stroke Empty 60MM/S Working 8MM/S Return 66MM/S Main Motor Type Y132M-4 Power 7.5KW Speed 1440R/MIN Max Working Pressure of Hydraulic System 25MPA Dimension 3290X1670X2450MM Weight 7.1TON
