Nc Control 16mm Sheet Metal Plate Shearing Machine
Shanghai YingXin World Machinery Co., Ltd.- After-sales Service：Available
- Automation：Automatic
- Certification：CE, ISO 9001:2000
- Condition：New
- Warranty：1 Year
- Plate Shearing Machine：Guillotine Type Cutting Machine
Base Info
- Model NO.：QC11Y
- Cutting Thickness：16mm Maximum
- Transport Package：in Container
- Specification：ISO9000
- Trademark：WORLD
- Origin：Jiangsu
- HS Code：84629910
- Production Capacity：1000PCS,Year
Description
hydraulic press brake and cnc press brake
- hydraulic press machine
Specifications
- hydraulic press machine
Specifications
| Items | unit | QC11Y-6x2500 | QC11Y-6x3200 | QC11Y-6x4000 |
| Max. cutting thickness | mm | 6 | 6 | 6 |
| Max. cutting width | mm | 2500 | 3200 | 4000 |
| Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
| Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
| Travel distance of back gauge | mm | 20-550 | 20-550 | 20-600 |
| Throat depth | mm | 150 | 150 | 150 |
| Stroke speeds | spm | 16-26 | 12-22 | 10-20 |
| Main motor | kW | 7.5 | 7.5 | 7.5 |
| Length | mm | 3000 | 3700 | 4800 |
| Width | mm | 1500 | 1650 | 1650 |
| Height | mm | 2000 | 2050 | 2250 |
| Items | unit | QC11Y-8x2500 | QC11Y-8x3200 | QC11Y-8x4000 |
| Max. cutting thickness | mm | 8 | 8 | 8 |
| Max. cutting width | mm | 2500 | 3200 | 4000 |
| Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
| Cutting angle | deg | 0.5-2 | 0.5-2 | 0.5-2 |
| Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
| Throat depth | mm | 150 | 150 | 150 |
| Stroke speeds | spm | 14-25 | 12-20 | 10-20 |
| Main motor | kW | 11 | 11 | 11 |
| Length | mm | 3040 | 3860 | 4800 |
| Width | mm | 1700 | 1700 | 1800 |
| Height | mm | 2150 | 2350 | 2480 |
| Items | unit | QC11Y-10x2500 | QC11Y-10x3200 | QC11Y-10x4000 |
| Max. cutting thickness | mm | 10 | 10 | 10 |
| Max. cutting width | mm | 2500 | 3200 | 4000 |
| Tensile strength of plate to be cut | N/mm2 | 450 | 450 | 450 |
| Cutting angle | deg | 0.5-1.5 | 0.5-1.5 | 0.5-1.5 |
| Travel distance of back gauge | mm | 20-600 | 20-600 | 20-600 |
| Throat depth | mm | 150 | 150 | 150 |
| Stroke speeds | spm | 12-20 | 10-20 | 10-18 |
| Main motor | kW | 11 | 15 | 15 |
| Length | mm | 3040 | 3860 | 4800 |
| Width | mm | 1700 | 1700 | 1800 |
| Height | mm | 2150 | 2350 | 2480 |
