Manual Tube Pipe Bender Machine

Zhangjiagang Caos Precision Machinery Manufacturing Co., Ltd.
  • Condition：New
  • Certification：ISO 9001:2008, CE
  • Automation：Manual
  • Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
  • Model：Sb50nc
  • Max Bending Radiu：250mm

Base Info

  • Min Bending Radiu：25mm
  • Max Wear Core：2210mm
  • Max Bending Angle：185
  • Bend Pipe Fittings Can Be Set：2,9
  • Max Hydraulic Pressure：14MPa
  • Machine Size：3500*700*1300
  • Weight：1200kg
  • Transport Package：Wood
  • Specification：SB50NC
  • Trademark：CAOS
  • Origin：China
  • Production Capacity：100set,Per Year

Description


Specification/ModelUnitSB50NCRemarkMax bending capabilitymmΦ50×3
1. The Minimum bending diameter based onthe pipe diameter
2.The Max bending diameter can accordingto the customers requirement
3.The Max length of mandrel can according to customers requirement
Max bending radiusmmR250Min bending radiusmmR20Max bending angleDegree185Max effective distance of mandrelmm2210Control System NC ControlMax elbow bend pipeUnit16Max storable sectionsUnit16×16Motor powerKW4Max. Hydraulic PressureMpa12Hydraulic System Control Electromagnetic ValveOil Tank CapacityL110Measurementmm3500×700×1300Weight of MachineKg1200
