• Model NO.：QC12k 8*5000
• Type：Cutting Machine,Shearing Machine
• Transport Package：Plastic Cover
• Specification：CE
• Trademark：ZYMT
• Origin：China
• HS Code：8462299000
• Production Capacity：3000sets,Year

TypeCutting thickness(mm)Cutting length(mm)Angle range(°)Material strengthTravel timesPowerWeightDimension
L*W*H*(mm)4*2500425001°30'≤450105.538003040*1610*16204*3200432001°30'≤450105.550003840*1610*16204*4000440001°30'≤45085.565004600*1700*17004*6000460001°30'≤45057.5110006460*2100*32006*2500625001°30'≤450107.550003040*1610*16206*3200632001°30'≤45097.560003840*1610*16206*4000640001°30'≤45087.580004620*1750*17006*5000650001°30'≤45067.5105005400*1750*17006*6000660001°30'≤450511165006480*2100*23008*2500825001°30'≤450107.560003040*1700*17008*3200832001°30'≤45087.572003860*1700*17008*4000840001°30'≤45087.588004640*1700*17008*5000850001°30'≤45087.5115005400*2400*20008*6000860001°30'≤450811180006480*2100*235010*25001025001°30'≤45091173003040*1700*170010*32001032001°30'≤45091180003860*1700*170010*40001040001°30'≤450811120004650*2100*200010*60001060002°≤450515240006500*2100*230012*25001225002°≤450918.590003140*2150*200012*32001232002°≤450918.5108003880*2150*200012*40001240002°≤450818.5130004680*2150*200012*50001250002°≤450618.5160005900*2150*200012*60001260002°≤450518.5290006900*2600*270012*80001280002°≤450518.54650009000*3500*350016*25001625002°30'≤450918.5110003140*2150*200016*32001632002°30'≤450818.5130003880*2150*200016*40001640002°30'≤450818.5163004650*2150*220016*50001650002°30'≤450618.5200005900*2600*270016*60001660002°30'≤450522360006900*2700*270020*25002025003°≤450822155003440*2300*250020*32002032003°≤450822180004150*2350*270020*40001040003°≤450522210004850*2350*270025*25002525003°≤450837190003200*2700*290025*32002532003°≤450537230004200*2700*290025*40002540003°≤450537270003850*2700*290030*25003025003°≤450537235003300*2900*290030*32003032003°≤450537275004200*2900*2900

Features:
1:The machine is fitted with CNC controller special for shearing machines.
2:The position of rear stopper is displayed in real-time manner.
3:Multi-step programming function is available and the rear stopper is able for automatic operation and continues positioning, to achieve an automatic adjustment for position of rear stopper.
4:It is provided with counting function for shearing , to display the shearing numbers in a real-time manner ,able for power-failure memory of position of rear stopper, procedures, and parameters.
5:Backgauge with precision ball screw and linear guide, to ensure the positioning precision, so that bring the higher precision processing.





 Optional controllers

E200S
Back gauge control, bus mode control servo system;
Stroke length limitation, double programmable digital output;
Program memory of up to 40 programs, up to 25 steps per program;
One side positioning, retract function;
Mm/inch transmission, Chinese /English transmission;
240*128 pixels LCD display.

E21S
Back gauge control, control for general AC motor, frequency inverter;
Intelligent positioning, double programmable digital output;
Stock counter, program memory of up to 40 programs, up to 25 steps per program;
One side positioning, retract function;
One key backup, restore of parameters;
Mm/inch transmission, Chinese/English transmission;LCD display.

P40
analog or digital outputs for 1-3sreed operation
16 free programmable digital in-/outputs
program memory(1000 sets)
angle control/ gap control/ back gauge
limitation of the cutting length
material of the cutting length
material list for angle and gap control


HT071
regulated power supply for encoder or push pull/o.c.
optical line 12 vdc ±5% 120ma
optoisolated inputs
high luminosity led display having 6 digits plus sign for position
2 digits for cycles and for programs
possibility to save up to 99 programs composed of 20 cycles
each cycle can count 65000 repetitions at maximum
data and programs are saved in a flash memory without floating battery
IP65, polycarbonate, water and abrasion-proof keyboard with tactile sensitivity


Our service
1:Established over 100 sales and service outlets in the country's 29 provinces, municipalities and also the establishment of foreign 72 sales points, machine sales, spare parts supply, maintenance, technical advice and a range of services for users at hone and abroad.
2:We have a specialized group in charge of the whole business process.Pre-sales to be a staff, the sales is a friend, and after-sales we are partners.

Packing&Delivery:

With more than 10 years exporting experience, we are so skilled for loading containers and packing the machines in container for safety. Each machine use min. 6mm dimeter steel rope to fix the four angles with the container, to avoid the machinery equipment move in the container.

Certifications:
