• Model NO.：HJ-005
• Trademark：Hangji
• Origin：Shaanxi, China
• HS Code：8455213000
• Production Capacity：1000sets,Year

Basic Info.

Model NO. HJ-005 Trademark Hangji Origin Shaanxi, China HS Code 8455213000 Production Capacity 1000sets/Year

Product Description

Gripping shear
The function of the gripping shear
The gripping shear is located in the entrance of the pre-finishing mill and finishing mill, it is used to protect the pre-finishing mill and finishing mill by cutting off the rolled piece and stop further feeding into the mill once there is an operation failure.
Main technical performance

Steel types be processedGeneral Carbon Steel, Low-alloy steel
Shear temperature>950º C
Shear cylinderφ 100/φ 32× 240
Cylinder working pressure 0.4~0.6MPa
Equipment composition and structural characteristics
The gripping shear is composed of support base, main machine of cutting and cylinder, cutting machine is two spindle stuck shear that controlled by pneumatic, one is on top of rolling parts and the other is under the rolling parts, when accident occurs, cylinder moved through the closed sword by promote upper and lower connecting rod, these two swords connected with the moving rolling part and cut down it.
The support base of gripping shear is weld structure.
Lubrication and air compression:
The frame axis of gripping shear adapt oil bearing, the others used manual glycerol lubrication to offer the oil regularly.
The compressed air used in cylinder of the gripping shear is supplied by workshop, the pressure is 0.4~0.6Mpa.


What we can provide:
1. Completely rolling mill solutions including rolling passes design, production line setup, and workshop layout according to customer's requirements.
2.  Experienced skills of rolling mill and auxiliary equipment /spare parts used in the rolling mill production line. (Such as roller box, gearbox reduction, coil laying head, vertical and side loops, flying shears, pinch roll machine ,cooling bed , TMT systems etc.)
3. Technical services and post-sale technical supports. Also can adjust the production line or develop and improve the capacity in the future.
4. Professional engineers available for overseas installation and maintenance .
