WC67Y/K 200T / 3200mm electro-hydraulic servo sheet plate press brake
Shaanxi HAVEN Equipment Co., Ltd.- Waterproof Rating：IPX-1
- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000, ISO 9001:2008, CE
- Automation：Semi-Automatic
- Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.：WC67K-200,3200
- Type：Hydraulic Bending Machine
- Steel Body：Digital Readout E21
- Type for Fold-bending Machine：Hydraulic Fold-bend Machine
- Rated pressure：2000kn
- working table length：3200mm
- Distance between housing：2600mm
- Power supply：380V,50Hz,3pH or as your demand
- Machine color：As your demand
- Transport Package：Steel Pallet
- Specification：CE, ISO, SGS
- Trademark：HAVEN
- Origin：China
- HS Code：8462
- Production Capacity：100unit,Month
Description
modelNormal pressure(kn) Working table length (mm) Distance between housing Throat depth (mm) RAM travel (mm) Max. open height Adjust- ment of RAM travel (mm) Working table Height (mm) Main motor speed Oil flow rate (L/min) Machine overall Dimension (mm) L x W x H Machine weight(T) Power (kw) Speed (mm/s) Approach/ Working/ return 30X1300 300 1300 1110 200 40 275 80 710 3 1440 8 / 6 / 8 10 1800X1550X1900 1.8 30X1600 300 1600 1225 200 40 275 80 710 3 1440 8 / 6 / 8 10 1950X1550X1900 2.1 40X1300 400 1300 1080 200 100 275 80 710 4 1440 8 / 6 / 8 10 1950X1550X1990 2.1 40X1600 400 1600 1200 200 100 320 80 710 4 1440 8 / 6 / 8 10 1950X1550X1900 2.3 40X2000 400 2000 1500 220 100 320 80 730 4 1440 8 / 6 / 8 10 2150X1600X1980 2.8 40X2200 400 2200 1500 220 100 320 80 740 4 1440 8 / 6 / 8 10 2250X1700X1950 3 40X2500 400 2500 2000 220 100 320 80 730 4 1440 8 / 6 / 8 10 2505X1125X2000 3.1 50X2500 500 2500 1900 250 120 300 120 750 5.5 1440 8 / 6 / 8 10 2570X1270X1800 3.3 50X3200 500 3200 2600 250 120 300 120 750 5.5 1440 8 / 6 / 8 10 3270X1350X1960 3.2 63X2000 630 2000 1500 250 100 360 100 770 5.5 960 8 / 6 / 8 25 2060X1725X2280 3.8 63X2500 630 2500 2050 250 100 360 100 770 5.5 960 8 / 6 / 8 25 2560X1725X2280 4.2 63X3200 630 3200 2600 250 100 360 100 770 5.5 960 8 / 6 / 8 25 3260X1700X2260 5.5 80X3200 800 3200 2600 250 100 360 100 780 7.5 960 8 / 6 / 8 25 3520X1620X2230 6.6 80X4000 800 4000 3200 250 100 360 100 780 7.5 960 8 / 6 / 8 25 4050X1820X2280 7.5 100X2500 1000 2500 2050 320 130 390 100 850 7.5 960 8 / 6 / 8 25 2600X1750X2230 6.8 100X3200 1000 3200 2600 320 130 390 100 850 7.5 960 8 / 6 / 8 25 3500X1750X2230 7.2 100X4000 1000 4000 3200 320 130 390 100 850 7.5 960 8 / 6 / 8 25 4060X1800X2500 8.2 100X5000 1000 5000 4080 320 130 390 100 850 7.5 960 8 / 6 / 8 25 5100X1800X2700 9 125X2500 1250 2500 2050 320 130 390 100 850 11 960 8 / 6 / 8 25 2600X1750X2330 7.8 125X3200 1250 3200 2600 320 130 390 100 850 11 960 8 / 6 / 8 25 3500X1750X2330 7.5 125X4000 1250 4000 3200 320 130 390 100 850 11 960 8 / 6 / 8 25 4080X1750X2500 7.5 125X5000 1250 5000 4080 320 130 390 100 850 11 960 8 / 6 / 8 25 5080X1750X2600 7.5 160X3200 1600 3200 2600 320 200 470 160 840 11 960 7 / 5 / 7 25 3400X2100X2520 10.5 160X4000 1600 4000 3200 320 200 470 160 840 11 960 7 / 5 / 7 25 4060X2100X2600 11.8 160X5000 1600 5000 4080 320 200 470 160 840 11 960 7 / 5 / 7 25 5080X2100X2600 14 160X6000 1600 6000 4800 320 200 470 160 840 11 960 7 / 5 / 7 25 6100X2100X2680 15.8 200X3200 2000 3200 2600 320 200 520 180 850 15 960 7 / 5 / 7 63 3400X2200X2650 12.8 200X4000 2000 4000 3200 320 200 520 180 850 15 960 7 / 5 / 7 63 4080X2200X2650 14.5 200X5000 2000 5000 4080 320 200 520 180 850 15 960 7 / 5 / 7 63 5100X2200X2660 16 200X6000 2000 6000 4800 320 200 520 180 850 15 960 7 / 5 / 7 63 6120X2200X2660 17.5 250X3200 2500 3200 2600 400 250 560 220 865 18.5 960 7 / 5 / 7 63 3400X2300X2800 13.5 250X4000 2500 4000 3200 400 250 560 220 865 18.5 960 7 / 5 / 7 63 4120X2300X2800 15 250X5000 2500 5000 4080 400 250 560 220 865 18.5 960 7 / 5 / 7 63 5100X2300X2850 17 250X6000 2500 6000 4800 400 250 560 220 865 18.5 960 7 / 5 / 7 63 6120X2300X2900 19
