• Model NO.：GM-120CNC-2A-1S
• Type：Pipe and Tube Bending Machine
• Certificate：ISO9001: 2000
• Applicable Material：S. S, M. S., Copper, Aluminium, Alloy, Galvanized
• Applicable Shape：Round, Rectangle, Square, Oval, Solid Bar, Profile
• Bending Drive：Hydraulic
• Technical：Cold Bend
• Transport Package：Iron Frame,Wooden Case
• Specification：CE
• Trademark：GMACC
• Origin：China
• HS Code：8462219000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. GM-120CNC-2A-1S Type Pipe and Tube Bending Machine Certificate ISO9001: 2000 Applicable Material S. S, M. S., Copper, Aluminium, Alloy, Galvanized Applicable Shape Round, Rectangle, Square, Oval, Solid Bar, Profile Bending Drive Hydraulic Technical Cold Bend Transport Package Iron Frame/Wooden Case Specification CE Trademark GMACC Origin China HS Code 8462219000 Production Capacity 5000PCS/Year

Product Description

1. Totally Automatic
2. PLC, Servo Motor: Mitsubishi/Delta
3. Hydraulic valve: Japan Yuken
4. Hydraulic pump: Japan Yuken
5. High Efficiency/Stability

The series was adapted in particular to professional world market requirements. All the parts, structure and characters are similar to the standard of mechanical engineering from Europe. Our professional experience and drawings plans for Electric, Electronic, Hydraulic and mechanical from known companies bring to upgrading of the machines' systems to accurate and attractive performance.

Tooling including: Bending die, clamp die, pressure die, mandrel, mandrel rod, wiper die(optional), ball mandrel(optional)

Features:
1. Applicable tube material: Carbons steel, mild steel, soft steel, stainless steel, aluminum, alloy, copper, brass etc.
2. Applicable tube shape: Round, solid bar, square, rectangle, oval, profile etc.
3. Controlled through PLC and possesses manual, semi-automatic and full-automatic functions.
4. Y, B, C three coordinates of motion under precision control by PLC realizing full-auto mandrel on or mandrel off rapid bending.
5. Equipped with hydraulic-operated clamping tube, encoder-controlled bending angle with precision more or less 0.1 degree.

6. About 200 programs can be input into PLC, then show on dialogue-style operation touch screen, easy to learn and understand.
7. Various Touch screen language are available for choice as per request.
8. Adoption of hydraulic valve and oil way board can control actions individually to prolong the lifespan of hydraulic parts.
9. Guiding Die has auxiliary pushing function and at the same time it possesses Reiteration and entering repeat functions that can make the guiding module length shorten.
10. Counter function can accurately count work piece's quantity and save data whether in power-on or power-off situation.

11. Possess automatic error detection function and limit protecting function, Removing or changing faults easily and quickly.
12. Build-in battery enables to keep inside data for 3 years memory after turned Off machine.
13. Moveable foot switch with function of auto-start, pause and emergent-stop.
14. Optional function of core reversing slowly.
15. Optional function of slow bending.
16. Optional function of anticipated mandrel extraction.

Name	Unit	Parameter
Max.   Bending  Capacity	mm	120*6
Bending  Radius  Range	mm	40-500
Max.   Bending  Angle	°	190°
Bending  Speed	° /sec	2800
Turning  Speed	° /sec	20
Feeding  Speed	mm/sec	160
Bending  Precision	°	500
Turning  Precision	°	± 0.10
Feeding  Precision	mm	± 0.10
Turning  Servomotor  Power	kW	± 0.10
Feeding  Servomotor  Power	kW	3
Though  Effective  Distance	mm	3200
System  Motor  Power	kW	15
Max.   Pressure	Mpa	16
Oil  Pump  Delivery  Volume	L	36
L*W*H  (Packaging  Dimension)	mm	6500*1350*1300
Weight	T	5.8
