CNC Saw Machine Center for Aluminum Profile

Jinan Tianchen Smart Machine Co., Ltd.
  • Condition：New
  • Certification：ISO 9001:2000
  • Automation：Automatic
  • Suitable for：Aluminum
  • Transport Package：Standard Export Package
  • Specification：About7000kg

Base Info

  • Model NO.：LJVE-CNC-6000
  • Trademark：Tianchen
  • Origin：Jinan, Shandong Province
  • HS Code：84614090
  • Production Capacity：300sets,Year

Description

Basic Info.

Model NO. LJVE-CNC-6000 Trademark Tianchen Origin Jinan, Shandong Province HS Code 84614090 Production Capacity 300sets/Year

Product Description

  1. Main purpose and applications:
  1. It is used for high effective cutting aluminum profile at 45°or 90°.
  2. The auto worktable continuous feeding and clamping profile.
  3. It adopts high precision straight guide rail pair to ensure stability and reliable operation.
  4. Load mechanical arm adopts Siemens servo drive can reach to three axis (X, Y, Z) auto control. Imported high precision gear rack drive to ensure reliable feeding.
  5. Blade connected with imported motor. Cut smooth, steady and high precision.
  6. Siemens control system makes machine working steady and reliable.
  7. It can complete the 45°cutting through up and down saw blade respectively cutting, high cutting precision, which can avoid partial breakage of profile.
  8. It can continuously complete profile ±45° or 90° cutting, high processing efficiency.
  9. Unload mechanical arm adopts servo driver, which can realize fast unloading, positioning function and be able to reach the auto output of the shortest profile 260mm.
  10. Roller linear guide pair and ball screw equipped with auto lubrication system, improve the precision and service life.
  11. Hinge type constantly conveys scrap and aluminum scrap to the outside.
  12. The totally enclosed safety cover to ensure the personal security.
  13. Option: Profile lifting platform to achieve the single person feeding operation
  14. Option: Bar code printer for E-works.
  1. Technical parameters:
Cutting motor power:3×3.0 kW
Total power:18kW
Power supply:380V 50Hz
Operation air pressure:0.6~0.8MPa
Air consumption:150L/min
Blade specification:Ф550×Ф30×4.4×120T
Cutting height:30~140 mm
Cutting width:30~100 mm
Raw materials:260~5800 mm
Cutting angle deviation:±5′
Length deviation:±0.15mm
Repeat locating length deviation:±0.05mm
Contour dimension:14000×5000×2500 mm
Weight:7000 kg
