Auto Double Head Bending Machine

ACE Machine Tools Co., Ltd.

    Base Info

    • Model NO.：GM-DB 38B,42B

    Description

    Main Technical Parameter Unit 38B 42B
    Max. Bending Capacity mm  38×2  42×2
    Bending Radius Region mm 38-220 42-250
    Center Region of Double Head mm 170-1450 170-1450
    Max. Bending Angle ° 185 185
    Bending Speed °/sec 50 50
    Pieces of one Time Bending piece  13×3  15×3
     19×2  25×2
    Max. Pressure Mpa 16 16
    The Discharge of Oil Pump L 17 22
    Capacity of Oil Tank L 120 120
    Power of Motor kw 5.5 5.5
    Machine Weight kg 2500 3500
    Machine Dimension mm 2700×900×1350 2700×900×1800
