• Model NO.：HHW-2F HHW-3F HHW-4F
• HS Code：84622990
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. HHW-2F HHW-3F HHW-4F HS Code 84622990 Production Capacity 1000PCS/Month

Product Description

The hydraulic pipe benders HHW-2F/3F/4F comes with separate hand pump, which provides more flexibility and safety for the operate

Our professional pipe bender features reliability, durability and extra safety for operators.

Model: HHW-2F
Max. Pressure: 16T
Max. Stroke: 250mm
Crimp range: Φ 21.3mm-Φ 60mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2"
Pipe wall thickness: 2.75mm-4.5mm
G. W.: 50kg
Volume(cm): 73*32*20

Model: HHW-3F
Max. Pressure: 20T
Max. Stroke: 320mm
Crimp range: Φ 21.3mm-Φ 88.5mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2" 21/2" 3"
Pipe wall thickness: 2.75mm-5mm
G. W.: 112kg
Volume(cm): 93*40*21

Model: HHW-4F
Max. Pressure: 23T
Max. Stroke: 370mm
Crimp range: Φ 21.3mm-Φ 108mm
Bending formers(in): 1/2" 3/4" 1" 11/4" 11/2" 2" 21/2" 3" 4"
Pipe wall thickness: 2.75mm-6mm
G. W.: 157kg
Volume(cm): 118*46*23
