European Market Popular Wire Feeding Speed 60m / Min 3D CNC Universal Wire Bending Machinery
Beijing Ron-En Machinery & Integration Co., Ltd.- After-sales Service：Provide Solutions Within 24
- Waterproof Rating：IPX-0
- Warranty：1-year
- Condition：New
- Certification：CE
- Automation：Automatic
Base Info
- Model NO.：Ronen-015
- Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
- Type：Beading Machine
- Transport Package：Wooden Packaging
- Specification：Metal
- Trademark：RONEN
- Origin：Hebei, China
- Production Capacity：10 Set,Sets Per Month
Description
Forming Wire Bending Machine Technical Parameter:
| Name | WIRE FORMING MACHINE |
| Shape of production | 3 D |
| Processing line diameter | Soft wire 3.0-10.0mm |
| The highest Feed velocity | 70m/min |
| The minimum time required to turn head to fold 90 ° | 0.1 s |
| Reverse the core minimum time required to convert | 0.1 s |
| Minimum time required to roll wire 90 ° | 0.5 s |
| The highest speed of platform movement | 300 mm/s |
| The highest speed reverse mechanism | 250 mm/s |
| The largest feed limit | No limited |
| Feeding way | Roller wire feeding |
| Maximum bending radius | 30 mm |
| Bending speed | 180 deg/0.5s |
| Rotation speed | 180 deg/1.0s |
| Feeding speed | 900 mm/1.0s |
| Input data style | direct / teaching |
| Bending motor power | 2.7 Kw |
| Feeding motor power | 4.5 Kw |
| Electric capacity | 15.0 KVA |
| Net Weight | 3400 KG |
| Size : L*W*H | 4300*1600*1650 |
Company Information"RONENFORM" BG(a member of RGL) is dedicated to manufacturing series of Wires/Springs Forming Machines, Tubes Bending Forming Machines, and various auxiliary equipment and spare parts. The company is headquartered in Beijing, and its manufacturing workshop is located in Baoding and Cangzhou. It provides high quality equipment for domestic and foreign pipe and auto parts customers, with rich experiences of serving the industrial field for more than 20 years, "RONENFORM" becomes a reliable professional wire/tube forming equipment supplier and life time partner. "RONENFORM" does not only provide machines, but also the know-how on specific products thanks to backup by a technician team consists of many top professors-being called "Craftsman", we are confident to guarantee all our customers that our manufacturing level /serving level ranks at the top all over China. We follow up the principle of "ZERO FAULT"on each steps of business with you.
RONENFORM will always be here for you!
Metal Wire Forming Bending Machine Description
European Market Popular Wire Feeding Speed 60m / min 3D CNC Universal Wire Bending Machinery
American Market Quality Auto 3D CNC Wire Bender /Automatic 3D CNC Wire Forming Machine Metal Bending Machine/Steel Bar Bending Machine
Steel Wire Bending Machine Product Advantages:1. In principle, the head turning molding machine has the advantages of no turning, light head structure and no turning, which ensures the fast and stable production operation.
2. Computer power on, power off fast, simple and convenient operation. The computer interface can adjust the speed and change the program at the same time of production.
3. High speed motor imported from Japan and reducer imported from Germany are used in the configuration. The production speed is more than 25% higher than that of domestic counterparts.
4. Wire feeding and rotating arm are separated and matched. When the head is turned, the wire can not be turned, and the small outer diameter arc and multi circle products can be formed.5. The production can realize that the angle does not change at the slowest angle, and the production stability is better.
6. Bearing, gear and other important parts are imported from Taiwan, with 8760 hours guarantee, and the equipment is durable and reliable.
7. High precision, can do 2.0-14 mm wire diameter range of wire forming products, error reduced to 0.1 mm
8. The matching use of the steel wire butt joint machine makes the line changing operation of the machine more convenient.
Ronen Group Company Catalog
Ronen Group Exhibition Information
Certifications
FAQ
1.Q:Are you manufacturer?
A:Yes, We are manufacturer.
2.Q: What are the payment terms?
A: Pattern of pattern :we can accept L/C ,T/T , Western Union , Money Gram
3. Q: What is the whole business flow cooperation with us ?
A:1.Firstly,send your inquiry to us,make us have learned your requirement
2.We will be drawing a proforma invoice according to your requirement ,and start production after you finished to pay
30% deposit.
3.All of the goods, packing details, and B/L copy will be send to buyer after finished production. We will arrange
shipment and provide original B/L after the buyer finished to pay the balance.
4. Q: What if you encounter technical problems?
A:Please contact us as soon as possible and let us know what kind of technical problems you encounter and the
details. We will give you a solution within 24 hours.
5. Q: What advantages we have?
A: Rich experience: We have been in this line for 20 years . we can provide solution according to the problem of the buyer meet in the production process.
