• Model NO.：ZNC-1500A*3000
• Type：CNC
• Cutting Gas：Oxygen+Acetylene or Propane
• Cutting Thickness：5-150mm
• Cutting Speed：0-2000mm,Min
• Transport Package：Carton with Wooden Case
• Specification：AC110,220V, 50,60Hz
• Trademark：CHD
• Origin：Shanghai
• HS Code：8456401000
• Production Capacity：2000 PCS,Year

ProductZNC-1500A portable CNC cutting machineModelZNC-1500Ax2500ZNC-1500Ax3000Input voltageAC 220VAC 220VPower supply frequency50Hz50HzRated power500-1000W500-1000WEffective cutting width1500mm1500mmEffective cutting length2500mm3000mmcould be customized (Max. Length: 7500mm)Cutting modegas / plasma cuttinggas / plasma cuttingMotor stylestep motorstep motorDrive modesingle-sidesingle-sideGas cutting thickness6-100mm6-100mmPlasma cutting thicknessDepends on plasma source capacityCutting speed10-3000mm/min10-3000mm/minWorking precision±0.3mm/meter±0.3mm/meterCutting gasOxygen + Acetylene/ PropaneGas pressureOxygen: ≤1MpaFuel: ≤0.1MpaTorch height control modeElectric motor drive torch height controlDisplay screen7"LCD color screenNesting softwareFASTCAM
Configuration:
With thicken steel rail,electric control automatic torch lift, reserve plasma cutting interface,includes a piece of FastCAM Portable Nesting Software. Effective cutting length can reach to 7.5 meter. For prolong the machine, 220USD/METER.
For flame cutting only,not with arc voltage lift


FAQ:

Q: Are you a manufacturer or trading company?
A: We are manufacturer with the plant area of 24,000 square meter in Shanghai, and we have also production bases in Wenzhou and Chengdu.

Q: What material could the machine cut?
A: all kinds of metal plate, includes carbon steel, stainless steel, aluminium, copper and Zinc etc.

Q: what's the lead time or delivery time?
A: 7 working days

Q: what's Warranty?
A: 12 months

Q: How is your after-sales service?
A: Consumable parts will be supplied in free, shipped to you with your purchased machine.

Q: Is there oversea engineer available?
A: Our engineer could service you 24 hours online by Skype, or on cellphone, and they can   go to your country to service you if necessary.

Or you can tell us the following info, we'll suggest you the best item needed.

Material you'll cut.
Thickness of Material.
Cutting range (Length, width) you want.
Handheld torch or automated machine you prefer.


CHD brief introduction
CHD was founded in 1989, is a High-Tech Enterprise which integrates R&D, Production, Sales and Service of cutting machine.
CHD, as one of the largest metal cutting machine manufacturers, headquartered in Shanghai, China. With 3 production bases, totally plant area of more than 53,000 square meters , respectively located in Shanghai, Chengdu and Wenzhou.
CHD focus on quality control, has won many certification audits including ISO9000, SGS, CE, CCC, etc., was one of the world's largest manufacturer's partners of steel plate cutting equipment. CHD cutting machines have already been exported to more than 100 countries in the past 20 years.

Advantages of CHD:
Large Production Capacity. R& D stuff, Workers, 3 Production Bases, Plant of 53000 Square Meters. Production Line.
Full line of Products, including Cutting Machine, Plasma Power, Welding Machine, Beveling Machine, Circular Cooling Water Tanks, Consumables.
Honesty. All parameters (cutting thickness & precision) are actual operation parameters without overstate.
Good after-sales service, not one-off business.
One year guarantee. Free spare parts service on base of your order amount. Engineer oversea service.
Adjustable Short Lead Time.
