Hydraulic Powered Metal Sheet Cutting Nc Shear Machine

Shanghai YingXin World Machinery Co., Ltd.
  • After-sales Service：Available
  • Automation：Automatic
  • Certification：ISO 9001:2000
  • Condition：New
  • Warranty：2 Years
  • Nc Shear Machine：Metal Sheet Cutting Machine

Base Info

  • Model NO.：QC11Y
  • Power：Hydraulic Oil
  • Transport Package：in Container
  • Specification：ISO9001, CE
  • Trademark：WORLD
  • Origin：China
  • Production Capacity：2000PCS,Year

Description

hydraulic press brake and cnc press brake
-  hydraulic press machine

Specifications
ItemsunitQC11Y-6x2500QC11Y-6x3200QC11Y-6x4000
Max. cutting thicknessmm666
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-1.50.5-1.50.5-1.5
Travel distance of back gaugemm20-55020-55020-600
Throat depthmm150150150
Stroke speedsspm16-2612-2210-20
Main motorkW7.57.57.5
Lengthmm300037004800
Widthmm150016501650
Heightmm200020502250
ItemsunitQC11Y-8x2500QC11Y-8x3200QC11Y-8x4000
Max. cutting thicknessmm888
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-20.5-20.5-2
Travel distance of back gaugemm20-60020-60020-600
Throat depthmm150150150
Stroke speedsspm14-2512-2010-20
Main motorkW111111
Lengthmm304038604800
Widthmm170017001800
Heightmm215023502480
ItemsunitQC11Y-10x2500QC11Y-10x3200QC11Y-10x4000
Max. cutting thicknessmm101010
Max. cutting widthmm250032004000
Tensile strength of plate to be cutN/mm2450450450
Cutting angledeg0.5-1.50.5-1.50.5-1.5
Travel distance of back gaugemm20-60020-60020-600
Throat depthmm150150150
Stroke speedsspm12-2010-2010-18
Main motorkW111515
Lengthmm304038604800
Widthmm170017001800
Heightmm215023502480
