• Model NO.：DK7712
• Origin：China
• Production Capacity：5000

Basic Info.

Model NO. DK7712 Origin China Production Capacity 5000

Product Description

Product Description:

High precision: imported high rigidity and high strength guide rail, double nut ball screw and machine tool are adopted, and the manufacturing process parameters are 3 ~ 5 times higher than the national standard.
High finish: it adopts a variety of wire cutting methods and automatic wire tightening device, which can realize multiple cutting and fast wire walking machine for middle wire walking.
Speed: DK series high-speed and high-precision power supply and new environmental protection cutting fluid independently developed by Datong railway are adopted, the processing efficiency is 2 ~ 3 times higher than that of ordinary medium wire walking, and the cutting speed can reach 400mm2 / min.

Type	Worktable size (mm)	Worktable Travel (mm)	Max.cut thickness (mm)	Taper (optinal)	Max. Load  weight (kg)	Net weight (kg)	Dimensions (mm)	Power supply (kw)
DK7712	200x270	120X160	100	/	50	600	900X700X1250	2KW
DK7720	270x420	200x250	200	6°/80mm	100	800	1160X880X1400	2KW
DK7725	340x520	250x220	400	6-12°/80mm	200	1200	1485X1010X1700	2KW
DK7730	340x560	300x360	400	6-12°/80mm	200	1250	1485X1050X1700	2KW
DK7732	380x600	320X400	400	6-30°/80mm	300	1400	1640X1280X1700	2KW
DK7735	380X650	350X450	400	6-30°/80mm	300	1440	1660X1330X1700	2KW
DK7740	410x710	400x500	400	6-60°/80mm	450	1600	1830X1490X1700	2KW
DK7745	500x750	450x550	400	6-60°/80mm	450	1650	1865X1520X1700	2KW
DK7755	596x880	550x650	500	6-60°/80mm	800	2500	2070X1170X1790	2KW
DK7763	790x1260	630x1000	600	6-60°/80mm	1000	3500	2265X2160X1930	2KW
DK7780	900x1500	800x1200	600	6-60°/80mm	1500	5500	2900X2500X2150	2KW
DK77120	1300x1900	1200x1600	600	6-12°/80mm	4000	10000	4200X3700X2000	2KW
DK77160	1400X2500	1600X2000	800	6-12°/80mm	5000	12000	5000X4200X2200	2KW

Contact Us:

Ashley Liu TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 18266002891

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
