• Model NO.：LJVC-CNC-2*6000
• Trademark：Tianchen
• Origin：Jinan, Shandong Province
• HS Code：84614090
• Production Capacity：500sets,Year

Basic Info.

Model NO. LJVC-CNC-2*6000 Trademark Tianchen Origin Jinan, Shandong Province HS Code 84614090 Production Capacity 500sets/Year

Product Description

• Main purpose and applications:

1. This machine is designed for high effective cutting two pieces of aluminum profile at 45°or 90°
2. Worktable auto continuous feeding and clamping two pieces of profile.
3. It adopts high precision straight guide rail pair to ensure stability and reliable operation.
4. It equipped with automatic chip removal device to discharge the matreial and aluminum chips from automatically.
5. Mechanical arm adopts Siemens servo drive. Imported high precision gear rack drive to ensure reliable feeding.
6. Blade connected with imported motor. Cut smooth, steady and high precision.
7. Siemens control system makes machine working steady and reliable.
8. New way of blade return to avoid touching profile.
9. Totally enclosed safety cover to ensure personal security.
10. Option: Material lifting platform.
11. Option: Bar code printer.

Main technical parameter:

Cutting motor power	3×2.2kw
Input power	380V 50HZ
Operation air pressure	0.6-0.8MPa
Blade spec	φ500×φ30×4.4×120T
Profile height	20-100mm
Profile width	20-100mm
Profile length	350-5800mm
Cutting angle error	±5′
Length error	±0.2mm
Repeat locating length error	±0.05mm
Contour Dimension(W×H×L)	14000×5500×2000mm
Machine net Weight	6000kg
