High precision series hydraulic press machine
Shaanxi HAVEN Equipment Co., Ltd.- Waterproof Rating：IPX-1
- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000
- Automation：Semi-Automatic
- Suitable for：Plastic, Rubber, Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.：HPB-200,1600
- Type：Beading Machine
- Press Brake with Mould：Hydraulic Type
- Capacity：2000KN
- Pressure：30MPa
- Travel：300+400mm
- Table size：500X1550mm
- Net：3600KGS
- Packing size：250X95X225cm
- Worktable lenth：1600mm
- Transport Package：Veneer Box
- Specification：CE Standard
- Trademark：HAVEN
- Origin：China
- HS Code：8462
- Production Capacity：50 PCS,Month
Description
Basic Info.
Model NO. HPB-200/1600 Type Beading Machine Press Brake with Mould Hydraulic Type Capacity 2000KN Pressure 30MPa Travel 300+400mm Table size 500X1550mm Net 3600KGS Packing size 250X95X225cm Worktable lenth 1600mm Transport Package Veneer Box Specification CE Standard Trademark HAVEN Origin China HS Code 8462 Production Capacity 50 PCS/MonthProduct Description
High precisionHPB-150/1600, HPB-200/1600,HPB-300/1600 serieshydraulic bending machine* Hydraulic press include replaceable top tools v-block, and support table with stops.Table can be lifted through a chain driven by the main cylinder.
* Micro-switch for traverse adjustment.
* Operating modus:Semi-automatic, fully.
Main speicification:
| Model | Capacity | Power | Piston stroke | Weight | Dimension |
| HPB-490 | 490mm / 20t | 1.5kw | 220mm | 270kg | 120x55x168cm |
| HPB-580 | 580mm / 30t | 2.2kw | 220mm | 470kg | 100x45x155cm |
| HPB-790 | 790mm / 50t | 2.2kw | 220mm | 980kg | 146x60x175cm |
| HPB-1010/100 | 1010mm / 100t | 2.2kw | 250mm | 1400kg | 186x82x225cm |
| HPB-1010/150 | 1010mm / 150t | 3.0kw | 300mm | 1700kg | 186x82x225cm |
| HPB-1010/200 | 1010mm / 200t | 4.0kw | 300mm | 2100kg | 200x90x235mm |
