Automatic Aluminium Hydraulic Crimping Curving Bending Machine for Standing Seam
Xiamen Xinhonghua Machinery Co., Ltd.- Condition：New
- Certification：SGS
- Automation：Automatic
- Type：Bending Machine
- Model No：Yx65-400,425
- Weight：1000kgs
Base Info
- Model NO.：YX65-400-425
- Hydraulic Power：5.5kw
- Voltage：415V,60Hz,3pH
- Effective Width：400mm,433mm
- Galvanized Thcikness：0.6-0.8mm
- Aluminum Thickness：0.6-1.0mm
- Min. Strike Radius：1m
- Working Speed：3-5m,Min
- Dimension：1500*1000*1800mm
- Transport Package：Standard Export Package
- Specification：SGS
- Trademark：XHH
- Origin：Xiame of China
- HS Code：8455229090
- Production Capacity：20 Sets,Month
Description
Basic Info.
Model NO. YX65-400-425 Hydraulic Power 5.5kw Voltage 415V/60Hz/3pH Effective Width 400mm,433mm Galvanized Thcikness 0.6-0.8mm Aluminum Thickness 0.6-1.0mm Min. Strike Radius 1m Working Speed 3-5m/Min Dimension 1500*1000*1800mm Transport Package Standard Export Package Specification SGS Trademark XHH Origin Xiame of China HS Code 8455229090 Production Capacity 20 Sets/MonthProduct Description
Specification:
The detail information of YX65-400/425 Automatic Hydraulic Metal Roof Panel Crimping Curving Machine, Metal Roofing Sheet Crimping Curving Machine informations are as follws:
Main Technic Data:
1. | Size | 1500*1000*1800mm |
| 2. | Weight | 1000KGS |
| 3. | Model | YX65-400-433 |
4. | Hydraulic Power | 5.5KW |
| 5. | Effective Width | 400mm,433mm |
| 6. | Voltage | 415V/60HZ/3PH |
| 7. | Aluminum Thickness | 0.6-1.0mm |
| 8. | Galvanized Thickness | 0.6-0.8mm |
| 9. | Min. Strike Radius | 1m |
| 10. | Working Speed | 3-5m/min |
