Model

Max cutting thickness

mm

Max cutting length

mm

cutting angle
°

Ram strokes

n/min

Back stop range

mm

Motor

kw

Machine size

mm

4x2500425001.301620-50043100x1400x17004x3200432001.301320-5005.53800x1560x17004x4000440001.301020-6005.54800x1650x17504x6000460001.30520-8007.56500x1800x21806x2500625001.301520-5007.53100x1600x17506x3200632001.301220-5007.53800x1600x17506x4000640001.30920-6007.54800x1650x17506x5000650001.30820-6007.55650x1830x22506x6000660001.30520-800116650x1890x23808x2500825001.301120-5007.53100x1650x17808x3200832001.30820-5007.53800x1650x18008x4000840001.30820-6007.54800x1650x18008x5000850001.30820-6007.55800x2000x25008x6000860001.30820-800116800x2100x270010x25001025001.301020-500113200x1750x175010x32001032001.301020-500113900x1750x180010x40001040001.301020-600114900x1800x185010x60001060001.301020-800156900x2210x280012x25001225002.01220-60018.53200x1800x180012x32001232002.01020-60018.53900x1800x180012x40001240002.01020-60018.54900x1850x190012x50001250002.0620-60018.55150x2150x280012x60001260002.0520-100018.56900x2300x310016x25001625002.301020-60018.53200x1850x230016x32001632002.301020-60018.53900x1850x240016x40001640002.301020-80018.54800x1950x259016x50001650002.0620-100018.56000x2250x290016x60001660002.0520-1000227000x2300x300020x25002025003.0820-800223200x1880x245020x32002032003.0820-800224100x1880x270020x40002040003.0520-1000224900x2150x285020x60002060003.0420-1000227000x2350x300025x25002525003.0820-1000373400x2000x270025x32002532003.0520-1000374100x2150x290030x25003025003.0420-1000373300x2900x300030x32003032003.30420-1000404200x2500x260040x25004025004.0320-1000753200x3300x320040x32004032004.0320-1000904300x3300x3000
