Portable Cold Pipe Cutting and Beveling Machine

Watt Machinery Technology Co., Ltd.
  • Waterproof Rating：IPX-7
  • Warranty：1-year
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Control：Automatic
  • Application：Metal

Base Info

  • Model NO.：L12
  • Power Source：Pneumatic
  • Layout：Horizontal
  • Automation：Semi Automatic
  • Pipe Dia. Range：6-12inch Od
  • Pipe Material：SGS,Ce,BV
  • Cutting Model：Blade Cutting
  • Customized：Customized
  • Function：Cut and Bevel
  • Package：Wooden Case
  • Suitable：on-Site Pipework,Oil and Gas Pipeline
  • Transport Package：Wooden Case
  • Trademark：Watt
  • Origin：China
  • HS Code：846190
  • Production Capacity：500

Description

Rotating speed (rpm)OD(mm) OD (inch) Single operation Multi operation L3 Ф10~90 3/8"~3" ≤25 / 34 L6 Ф25~168 1"~6" ≤25 ≤50 24 L8 Ф50~219 2"~8" ≤25 ≤50 23 L10 Ф114~273 4"~10" ≤25 ≤75 23 L12 Ф168~323 6"~12" ≤25 ≤75 23 L14 Ф219~355 8"~14" ≤25 ≤110 23 L16 Ф254~406 10"~16" ≤25 ≤110 22 L18 Ф323~457 12"~18" ≤25 ≤110 20 L20 Ф355~508 14"~20" ≤25 ≤110 20 L22 Ф406~559 16"~22" ≤25 ≤110 14 L24 Ф457~610 18"~24" ≤25 ≤110 14 L30 Ф610~762 24"~30" ≤25 ≤110 13 L36 Ф762~914 30"~36" ≤25 ≤110 11 L42 Ф914~1066 36"~42" ≤25 ≤110 10 L44 Ф980~1160 38"~44" ≤25 ≤110 9 L48 Ф1040~1240 40"~48" ≤25 ≤110 9 L51 Ф1150~1300 45"~51" ≤25 ≤110 8 L60 Ф1320~1540 52"~60" ≤25 ≤110 5 We can design and manufacture according to customer's requirement

Machine body structure and material:
1.Standard Model: Alloy steel with ionic nitriding treatment, the weight is a bit heavy but solid and durable;
2.Light Model: Aerospace grade aluminum alloy. Light weight and suitable for high-altitude operation.

Order Guide
Before you place order to us, please let us know the following information:
  • Choose the right Model
  • Confirm your electric power supply ( Voltage, frequency and phase)
  • Confirm the beveling angel required
  • Confirm the welding joint required (U, V, Double V or Compound preparation)
  • Advise your pipe material ( Carbon steel, stainless steel or others)
  • Other special demands about machine
  • The spare parts needed
  • Advise pipe wall thickness (Important)
