Hydraulic Three Roller Plate Tank Cylinder Wind Tower Rolling Machine
Wuxi Zhouxiang Complete Set of Welding Equipment Co., Ltd.- Waterproof Rating：IPX-0
- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000
- Automation：Automatic
- Suitable for：Carbon Steel
Base Info
- Model NO.：w11snc
- Type：Roller-Bending Machine
- Transport Package：Steel Frame
- Trademark：Zhouxiang
- Origin：China
- HS Code：8462299000
- Production Capacity：15sets,Month
Description
Model
Max thickness (mm)
Max width (mm)
Yield limit (MPa)
Min bending Dia. (mm)
Rolling speed (m/min)
Main motor power (Kw)
W11SNC-15×2000
15
2000
245
600
4
7.5
W11SNC-20×2000
20
2000
245
800
4
15
W11SNC-20×2500
20
2500
245
800
4
15
W11SNC-20×3000
20
3000
245
800
4
22
W11SNC-25×2500
25
2500
245
900
4
22
W11SNC-25×4000
25
4000
245
1400
4
30
W11SNC-30×2500
30
2500
245
1100
4
30
W11SNC-30×3000
30
3000
245
1200
4
37
W11SNC-30×4000
30
4000
245
1400
4
45
W11SNC-40×2500
40
2500
245
1400
4
55
W11SHNC-40×3000
40
3000
245
1600
4
55
Above are our standard model, it can be designed and manufactured according to customer's request.
Technical Features:
1. Upper and lower driving, it can finish the end prebending and rolling of metal plate without U-turn.
2. The upper roller is drum shaped roller, there's adjustable roller supporting device under the lower roller ,which an ensure the accuracy of products.
3. The pressing oil cylinder is positioned on the top place without rod pressing down, which can save energy consumption
4. The material of upper and lower rollers is 42 CrMo, the rollers adopt solid forging with good comprehensive mechanical performance, good core tenacity and high surface hardness, it is suitable for heavy load work with long service life.
5. This machine has an independent operating table to make operation convenient for workers and a safe connecting device, to ensure safety.
6. Economical and applicable, cost-effective, suitable for medium and thick plate rolling system.
