• Model NO.：PBB2020,1.2
• Max Sheet Thickness：1.2mm
• Clamping bar lift：45
• Folding angle：0-135 degree
• Gross Weight：640kgs
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：China
• HS Code：8462299000
• Production Capacity：25 PCS,Month

Basic Info.

Model NO. PBB2020/1.2 Max Sheet Thickness 1.2mm Clamping bar lift 45 Folding angle 0-135 degree Gross Weight 640kgs Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin China HS Code 8462299000 Production Capacity 25 PCS/Month

Product Description

METAL BENDING MACHINE

1. They have the function of air spring which can be installed inside the arm (optional)
2. With foot control, It is easy for operation and relax hands.
3. Our precision folding machine PBB serials features a pedal structure. We have applied for patent protection at home.
4. Our precision folding machine is used for bending the sheet metal parts. The upper blade can be dismantled for use. It can choose a combination of upper blades according to the abnormity degree and length of the workpiece.
5. MAIN TECHNICAL PARAMETER

MODEL	PBB1020/2.5	PBB1270/2	PBB1520/1.5	PBB2020/1.2	PBB2500/1.0
Max. working length(mm)	1020	1270	1520	2020	2520
Max. sheet thickness(mm)	2.5	2.0	1.5	1.2	1.0
Max. clamping bar lift(mm)	47	47	47	47	47
Folding angle	0-135°	0-135°	0-135°	0-135°	0-135°
Packing size(cm)	146X62X127	170X71X127	196X71X130	247X94X132	297X94X132
N.W/G.W(kg)	285/320	320/360	385/456	490/640	770/590
