Cutting & Fold-bend Machine

Stainless Steel Plate Press Brake, Metal Sheet Press Brake, Plate Press Brake Machine

Maanshan Middle Asia Machine Tools Manufacture Co., Ltd.
  • Waterproof Rating:IPX-8
  • Warranty:1-year
  • Condition:New
  • Certification:ISO 9001:2008, Ce
  • Automation:Automatic
  • Type:Press Brake

Base Info

  • Model NO.:WC67K- 50T,2500
  • Nominal Force(Kn): 500:Worktable Length(mm):2500
  • Application:Machinery & Hardware
  • Type for Fold-Bending Machine:Hydraulic Fold-Bend Machine
  • Transport Package:Plastic Cover
  • Specification:CE STANDARD
  • Trademark:ZYMT
  • Origin:China
  • HS Code:8462219000
  • Production Capacity:3000 Sets,Year

Description

                         YESFront and back protection fence                         YESBack gauge with ball screw                         YESBack gauge travel                         500MMEmergency button                         YESStainless Steel Plate Press Brake, Metal Sheet Press Brake, Plate Press Brake Machine
Stainless Steel Plate Press Brake, Metal Sheet Press Brake, Plate Press Brake Machine

Other standard equipments:
Segmented upper punch die 1set
Lower die in one piece
Stop fingers 3
Front supporting arms 2
Emergency stop button;
Back, left and right safty fence
Foundation bolts 1set
Manuals and diagram 1book

Parameters:TypeNominal Force
(KN)Worktable Length
(mm)Poles Distance
(mm)Throat Depth
(mm)Slider Travel
(times/min)Max Open
(mm)Power
(kw)40T/2200400220018502301003205.540T/2500400250018502301003205.550T/2500500250018502301003205.563T/2500630250019002501003205.563T/3200630320025602501003205.580T/2500800250019903001003207.580T/3200800320025603201003507.580T/4000800400032003201003507.5100T/25001000250019003201203507.5100T/32001000320026003201504007.5100T/40001000400032003201504007.5125T/320012503200260032015040011125T/400012504000320032015040011160T/320016003200258032020046011160T/400016004000290032020046011160T/500016005000390032020046011160T/600016006000490032020046011200T/320020003200248032020046011200T/400020004000290032020046011200T/500020005000390032020046011200T/600020006000490032020046011250T/320025003200245040025059018.5250T/400025004000290040025059018.5250T/500025005000390040025059018.5250T/600025006000490040025059018.5300T/320030003200245040025059022300T/400030004000290040025059022300T/500030005000390040025059022300T/600030006000490040025059022400T/320040003200240040025059030400T/400040004000290040025059030400T/500040005000390040025059030400T/600040006000490040025059030500T/500050005000390040025059045500T/600050006000490040032059045600T/500060005000290040032059055600T/600060006000490040032059055
Company Introduction:
1.Maanshan Middle Asia Machine Tools Manufacture Co.,Ltd founded in 2001.
2.Total number of emploee: 500
3.All kinds of sophisticated equipment more than 100 sets.
4.Production plant area:60,000.
5.Whole factory is controlled by ERP-Enterprise Resource Plan.
6.CE/SGS/ISO9001 certification.

We are producing below ranges of machines:
1.NC/CNC Press Brake
2.NC/CNC Shearing Machine
3,Rolling Machine
4.Iron Worker
5.Power Press
6.Hydraulic Press

Our Services

1.Shearing blades and accessories-Customized to your specifications
In our shearing blades, our focus is on first-class, practical, well-thought-out upper and lower tools. Our tools offer solutions to your application cases - even for complex technical ones.

2.Service package

Basic:we offer you rapid troubleshooting through telephone support and costs for on-site missions are reduced.

Special:Engineers available to service machinery overseas for the necessary maintenance.

Partner:Our located dealers or customers who sell or use our machines are fully behind you,they are our friendly partner and supply good advice to you.

3.Technical Service(After-sale service)

Packaging & Shipping


(1)before packing,the machine tool will be testing for 48 hours to ensure all the equipment is 100% qualitied. (2)before loading,stable package,professional and skilled loader reduce damage of product during transport.(3)after loading,our professional documentary staff will follow the order till the product departs from port.

If you have any demand, please contact me directly, or browse through our web site: leolivia.en.made-in-china.com
