W11 Series Mechanical Type 3 Rollers Rolling and Bending Machine
Shaanxi HAVEN Equipment Co., Ltd.- Waterproof Rating:IPX-1
- Warranty:1-year
- Condition:New
- Certification:ISO 9001:2000, ISO 9001:2008, CE
- Automation:Semi-Automatic
- Suitable for:Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.:W11-6x2500
- Type:Roller-Bending Machine
- Application:Machinery & Hardware, Textiles, Chemical, Medical
- Type for Cutting Machine:Rolling Machine
- Type for Fold-bending Machine:mechanical Type
- Machine:As your demand
- Power supply:380V,50Hz,3pH or as yoru demand
- Control voltage:24V
- Transport Package:Steel Pallet
- Specification:CE Standard, SGS
- Trademark:HAVEN
- Origin:China
- HS Code:8466
- Production Capacity:1000 PCS,Year
Description
Basic Info.
Model NO. W11-6x2500 Type Roller-Bending Machine Application Machinery & Hardware, Textiles, Chemical, Medical Type for Cutting Machine Rolling Machine Type for Fold-bending Machine mechanical Type Machine As your demand Power supply 380V/50Hz/3pH or as yoru demand Control voltage 24V Transport Package Steel Pallet Specification CE Standard, SGS Trademark HAVEN Origin China HS Code 8466 Production Capacity 1000 PCS/YearProduct Description
W11 Series Mechanical Type 3 Rollers Rolling and Bending Machine1) mechancial type;
2) three rollers;
3) 24V contorl voltage;
2. Our Services
1: Response in time after getting customer's claim
1: Provide solution in 1 day
2: Usually solve problem within 2 days
2. For big machine, Installation Service is available as per customer's requirement
3. Training Service
Our technician is available to your factory and offer training of how to use our machines. As well, you may send your technician to our company to learn how to operate machines.
4. Quality Guarantee
We guarantee the quality of machine (e.g. processing speed and working performance is the same as the data of samples making). We sign the agreement with detailed technical data.
We arrange final test before shipment. We run the machine for a few days, and then use customer's materials for test. After making sure machine is the best performance, then make shipments.
Model | Max. thickness (mm) | Max. width (mm) | Max. Bending speed(m/min) | Workpiece Min. Dia. (mm) | Top roller dia (mm) | Bottom roller Dia. (mm) | Dis. of bottom rollers (mm) | Main motor power(kw) | Net weight (t) | Overall Dimensions (cm) |
W11-6*2500 | 6 | 2500 | 7.0 | 500 | 190 | 170 | 260 | 7.5 | 4.6 | 431*121*133 |
W11- 6*3200 | 6 | 3200 | 7.0 | 500 | 240 | 200 | 310 | 11 | 7.2 | 520*140*120 |
W11-8*2000 | 8 | 2000 | 7.0 | 450 | 190 | 170 | 260 | 7.5 | 4.1 | 381*121*133 |
W11- 8*2500 | 8 | 2500 | 6.0 | 500 | 230 | 190 | 300 | 11 | 6.7 | 450*142*161 |
W11-10*2000 | 10 | 2000 | 6.0 | 500 | 230 | 190 | 300 | 11 | 5.9 | 405*142*161 |
W11-12*2500 | 12 | 2500 | 5.0 | 750 | 280 | 240 | 360 | 22 | 9 | 500*150*180 |
W11-12*3200 | 12 | 3000 | 5.0 | 650 | 280 | 240 | 360 | 22 | 12.1 | 500*150*180 |
W11-16*2500 | 16 | 2500 | 5.0 | 750 | 280 | 240 | 360 | 22 | 8.5 | 500*150*180 |
W11-16*3200 | 16 | 3200 | 5.0 | 900 | 340 | 280 | 440 | 30 | 15.6 | 630*160*190 |
W11-20*2000 | 20 | 2000 | 5.0 | 750 | 280 | 240 | 360 | 22 | 7.8 | 450*150*190 |
W11-20*2500 | 20 | 2500 | 5.0 | 850 | 340 | 280 | 440 | 30 | 14.7 | 560*160*190 |
W11-25*2500 | 25 | 2500 | 4.5 | 900 | 380 | 300 | 490 | 37 | 16.7 | 600*160*215 |
W11-25x3200 | 25 | 3200 | 4.0 | 1200 | 400 | 310 | 520 | 37 | 20.5 | 680*180*215 |
W11-30*2500 | 30 | 2500 | 4.0 | 1200 | 400 | 310 | 520 | 40 | 21.6 | 580*180*215 |
W11-30*3000 | 30 | 3000 | 4.0 | 1200 | 400 | 310 | 520 | 45 | 25.3 | 630*180*215 |
