MB8 100t/3200 CNC Sheet Metal Bending Machine

LZK CNC Machine Tool (Anhui) Manufacturing Co., Ltd.
  • Warranty：2-year
  • Certification：CE

Base Info

  • Model NO.：MB8 100T,3200
  • Automation：Automatic
  • Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel, Carbon Steel, Mild Steel
  • Type：Press Brake
  • CNC System：Delem Da53t
  • Axes：X, Y1, Y2,
  • Crowning：Mechanical Crowning
  • Pressure：100t
  • Max Bending Length：3200mm
  • Bending Thickness：4mm
  • Main Motor：Siemens
  • Electrical Conponents：Schneider
  • Hydraulic Valve：Bosch-Rexroth
  • Back Gauge：Servo Motor
  • Transport Package：20ot Container
  • Specification：3800x1900x2400mm
  • Trademark：Jiashida Machine
  • Origin：China
  • HS Code：8462219000
  • Production Capacity：100 Sets,Month

Description

MB8 Series E-Hydraulic CNC Press Brake with DA52S System 3+1 Axes Features:The frame is made of steel structure, left and right vertical plate, worktable and pressure plate are welded into a whole structure. After welding, the internal stress is eliminated by tempering, so the whole steel is good and the stability is high.Latest high-frequency responding hydraulic control technology, faster, more efficient and accurate.The oil cylinder has been forged, Quenched and tempered, fine grinding, hard chromium plating and other processes, and with the import of sealing ring, the phenomenon of oil leakage in customer service.The hydraulic system adopts the integrated hydraulic system of oil road to reduce the installation of the pipeline, and the appearance of the hydraulic system is beautiful and concise.The use of hydraulic deflection compensation gives access to uniform full length workpieces. Hydraulic deflection compensation consists of a set of oil cylinders under the worktable, which can make the table occurs relative movement and form an ideal convex curve, ensuring the relative positions with slider keep unchanged. Compensation valves are subject to plate thickness and properties of material to be bent.MB8 100t/3200 CNC Sheet Metal Bending Machine
