Marble Granite Steel Glass CNC Water Jet Cutter

ONEJET WATERJET CO.,LTD
  • After-sales Service：7X24h
  • Warranty：1 Year
  • Certification：CE
  • Condition：New
  • Control：CNC
  • Application：Metal, Rubber, Ceramic, Glass, Stone, Plastic, Leather, Fabric, Alloy

Base Info

  • Model NO.：ONEJET50-G30*15
  • Power Source：Electric
  • Style：Gantry
  • Type：Three-Axis
  • Working Range：3000X1500mm
  • Maxi Bearing Pressure：420MPa,60000psi
  • Pressure Adjustable：0-380MPa
  • Cutting Accuracy：0.1mm
  • Main Motor：Siemens
  • PLC：Siemens
  • Servos：Yaskawa
  • Soft Starter：Siemens
  • Guid Linear and Ball Screw：Hiwin&Tbi
  • Power：380,415
  • Transport Package：Pep Inside and Thin Film Outside, Fixed in Contain
  • Specification：3000X1500mm
  • Trademark：ONEJET
  • Origin：Guangdong, China
  • HS Code：84565000
  • Production Capacity：5 Sets Per Month

Description

TECHNICAL SPECIFICATIONSMachine DemensionWork Envelope180mm or customizedModelG20*15G25*15G30*15G30*20G40*20G20*60G25*60Working RangeX2000mm2500mm3000mm3000mm4000mm2000mm2500mmY1500mm1500mm1500mm2000mm2000mm6000mm6000mmCutting Acuracy±0.10mmRepositioning Acuracy±0.03mmLubricationAuto lubrication systemDriver motorsPanasonic/Yaskawa/WISEMaxi travel speedX,Y 9600mm/min; Z 5000mm/minCutting headThree axis headFive Axis AC  headNOSyetemNcstudio based on Windows 7ProgrammNcEditor, AutoCADCapacity filesDXF,G codes,nce,nc etcCovers and protectionsAll stainless steel covers with water & dust proof designControl hardwareIntel Core dual;RAM 4GB; HD SSD 250G; 19inch screen;wireless keyboard and mouse; two USBOptionalsESA SYSTEM/ECS SYSTEM/LANTEK Marble Granite Steel Glass CNC Water Jet CutterMarble Granite Steel Glass CNC Water Jet CutterMarble Granite Steel Glass CNC Water Jet CutterMarble Granite Steel Glass CNC Water Jet CutterMarble Granite Steel Glass CNC Water Jet Cutter
