• Model NO.：W11-4*2000
• Type：Roller-Bending Machine
• Raw Material：Sheet , Plate Rolling
• Material / Metal Processed：Carbon Steel
• Power：Semi-Automatic
• Machine Type：Semi-Automatic Rolling Machine
• Max Thickness of Coiled Plate：4mm
• Max Width of Coiled Plate：2000mm
• Yielding Limit of Sheet Metal：245MPa
• Coiling Speed：7m,Min
• Min Full Loading Diameter of Coiled Plat：380 mm
• Diameter of Top Shaft：180 mm
• Diameter of Bottom Shaft：170 mm
• Main Motor：3 Kw
• Central Distance Between Bottom Shafts：210 mm
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Weight：500kgs
• Transport Package：Fumigation Wooden Box
• Specification：4*2000mm
• Trademark：Aoxuan
• Origin：Maanshan
• HS Code：8455109000
• Production Capacity：500sets,Year

TECHNICAL PARAMETERS for 3-roller plate rolling machine 3 roller semi-automatic roll forming machine, mechanical roll bending machine,rolling machinModel typePre-Working Max. UpperUnderSideMotor LengthHeightWidthWeightbendinglength thickness (mm)(mm)(mm)power(mm)(mm)(mm)(kg) (mm)(mm)(mm)   (KW)    W11-6x250062500419017015034020125013803600W11-8x25008250062101901707.54660132013704600W11-10x250010250082302101907.54660132013705560W11-13x250013250010270250210115009143015207200W11-16x250016250013300270210114920146017308110W11-20x2500202500163303002401149701610184010570W11-25x2500252500203603302501550401680190011800W11-30x25003025002539036030018.550201980210015800W11-35x2500352500304303903302252802180220020700W11-45x2500452500354604203603056452585230030000W11-50x2500502500405104603904548002500245045000W11-55x2500552500455405104405560003050300049000

Certifications:

Packing Detail:
Each Semi-automatic rolling machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers
and ship them abroad.
Delivery Detail:
Shipped in 30 days after payment




Our Service
Pre-sales.
* Project design, performance introduction, technical agreement, contract signing, packaging * Inquiry and consulting support.
* Sample testing support.
In-sales. * We will provide you with the latest progress in the product assembly, packaging and transportation.
After-sales.
* We will provide free accessories for the damage to non - human parts. * Training how to install the machine, training how
to use the machine with video and so on * And our technical staff can go abroad to provide technical guidance.

Our Company:




Our workshop:



Customer & EXPO:



FAQ:
1. Are you the manufacture?Can we visit your factory? We are manufacturer and we are located in Anhui,China.And we have our
own design team for products design. And welcome you visit our factory and check our machine qualtiy on spot,any question will
be solved on spot at first time.

2.What's your main product and what is your main foreign market? Our main products are press brake,shears machine,press,cut
ting machine,locking machine ,auto duct line and related products. Our main foreign market are Asia, North America, Europe, Afr
ica.

3. What are the advantages of your machines?And how can i believe the quality of your product? The main configuration is to im
port quality products, and Professional product quality inspection teamensure machine in top-quality, precision and life. For exam
ple,Germany Bosch-Rexroth Valve group,Germany Siemens Main Motor,Schneider Electrics system and so on. Once tested as q
ualified .our machine would be sent out.So The quality of our product is stable and reliable.

4. And are you able to update the production process Information in time after placing our order? After confirming your order ,we
would keep you updated of production details of emails and photos.

5. Can we be your agent? Yes,we are looking for Global agent we will help agent improve the market ,and supply all the service
like machine technical problem or other after-sales problem, meanwhile ,you can get big discount and commission.

6. Payment terms? T/T, L/C, Western Union, Paypal, Alibaba Secure Payment ect. Buyer pays 30% by T/T to start this order, res
t 70%paid before shipment.

7.Are you provide product metal parts and provide us technical guidance? Wearing parts,Disassembly tool(free) are what we cou
ld provide.And we can give you technical guidance.Our technical staff can go abroad to provide you with technical guidance.

8. How long is your warranty? 13 months free warranty, life-long maintenance.

9.Do you accept customer Logo and customized ?we accept kinds of customized ,including logo and machine.
