• Model NO.：QC11K-12X3200
• Cutting width：3200mm
• Control system：DAC310,E200,DA52
• Brand：HAVEN
• Transport Package：Steel Pallet
• Specification：CE, SGS, ISO
• Trademark：HAVEN
• Origin：China
• HS Code：8459
• Production Capacity：30 Units,Month

Basic Info.

Model NO. QC11K-12X3200 Cutting width 3200mm Control system DAC310,E200,DA52 Brand HAVEN Transport Package Steel Pallet Specification CE, SGS, ISO Trademark HAVEN Origin China HS Code 8459 Production Capacity 30 Units/Month

Product Description

CNC Hydraulic Shearing Machine QC11K-12X3200








Model	Mild Steel(450MPA)	Cutting Length(mm)	Depth Of Throat(mm)	Back Gauge Range(mm)	Rake Angle Adjustment	Strokes Per Minute	Main Motor	L× W× H(mm)	Weight(t)
6× 2500	6	2500	80	750	0.5° -1° 30′	14	7.5	3100× 1725× 1900	5.3
6× 3200	6	3200	80	750	0.5° -1° 30′	12	7.5	3935× 1840× 1995	6.5
6× 4000	6	4000	80	750	0.5° -1° 30′	10	7.5	4650× 1840× 2075	7.5
6× 5000	6	5000	80	750	0.5° -1° 30′	8	7.5	5650× 1830× 2250	10.5
6× 5000	6	6000	80	750	0.5° -1° 30′	8	7.5	6650× 1980× 2380	15.2
8× 2500	8	6000	80	750	0.5° -1° 30′	14	7.5	3135× 1840× 2075	6
8× 3200	8	3200	80	750	0.5° -1° 30′	12	7.5	3850× 1750× 1980	6.8
8× 4000	8	4000	80	750	0.5° -1° 30′	10	7.5	4650× 1890× 2075	8.5
8× 5000	8	5000	80	750	0.5° -2°	7	15	5805× 2000× 2500	12.5
8× 6000	8	6000	100	750	0.5° -2°	7	15	6805× 2115× 2715	19.8
10× 2500	10	2500	120	750	0.5° -2° 30′	10	15	3195× 1915× 2205	8.2
10× 3200	10	3200	120	750	0.5° -2° 30′	8	15	3895× 1900× 2235	11
10× 4000	10	4000	120	750	0.5° -2° 30′	6	15	4695× 1970× 2270	9.15
10× 5000	10	5000	120	750	0.5° -2° 30′	5	15	5905× 2115× 2715	16
10× 6000	10	6000	120	750	0.5° -2° 30′	5	15	6905× 2115× 2800	22
12× 2500	12	2500	120	750	0.5° -2° 30′	10	15	3195× 1800× 2210	8.7
12× 3200	12	3200	120	750	0.5° -2° 30′	8	15	3895× 1800× 2240	9.8
12× 4000	12	4000	120	750	0.5° -2° 30′	6	15	4710× 1950× 2485	13.4
12× 5000	12	5000	120	750	0.5° -2° 30′	5	18.5	4905× 2115× 2800	20
12× 6000	12	6000	120	750	0.5° -2° 30′	4	18.5	7000× 2300× 3100	29
16× 2500	16	2500	120	750	0.5° -2° 30′	8	15	3215× 1970× 2340	9
16× 3200	16	3200	120	750	0.5° -2° 30′	7	15	3915× 1970× 2455	11
16× 4000	16	4000	120	750	0.5° -2° 30′	6	15	4715× 2010× 2590	15
16× 5000	16	5000	120	750	0.5° -3°	5	22	6000× 2300× 3000	23
16× 6000	16	6000	120	750	0.5° -3°	4	37	7000× 2300× 3100	36
20× 2500	20	2500	120	750	0.5° -3°	6	22	3235× 2020× 2465	11
20× 3200	20	3200	120	750	0.5° -3°	5	30	4150× 2065× 2755	18
20× 4000	20	4000	120	750	0.5° -3°	4	30	4955× 2125× 2885	21
20× 5000	20	5000	120	750	0.5° -3°	4	37	6000× 2300× 3050	29
25× 2500	25	2500	120	750	0.5° -3.5°	5	30	3465× 2075× 2710	15.3
25× 3200	25	3200	120	750	0.5° -3.5°	5	30	4120× 2200× 3000	21
25× 4000	25	4000	120	750	0.5° -3.5°	3	30	4950× 2200× 3150	26
30× 2500	30	2500	120	750	0.5° -3.5°	4	30	3465× 2070× 2770	17
30× 3200	30	3200	120	750	1° -3.5°	3	37	4200× 2300× 3200	23
