• Model NO.：DW-130CNC Full-automatic Pipe Bending Machine
• Type：Pipe and Tube Bending Machine
• Transport Package：Wooden Box
• Trademark：RUNTAI
• Production Capacity：300 Sets Per Year

Name

Unit

Model: 1,DW130CNCX2A-1S
2,DW130CNCX3A-2S

Remarks

Maximum Bending Pipe Diameter * Wall Thickness

mm

Φ130*8

1. Minimum Bending Radius

   mm

   R400

   Maximum Bending Radius

   mm

   According to the pipe diameter

   Maximum Bending Angle

   Degree

   190°

   Maximum Feeding Length

   Mm

   3500

   Feeding Mode

   1.Direct Feeding 2.Clamp-type Feeding

   Optional

   Working Speed

   Pipe Bending Speed

   Deg/sec

   30

   Pipe Rotating Speed

   Deg/sec

   160

   Feeding Speed

   Mm/sec

   800

   precision

   Feeding Precision

   mm

   ±0.15°

   Pipe Rotating Precision

   Degree

   ±0.1°

   Pipe Bending Precision

   Degree

   ±0.1

   Information input mode

   1. Bend way

      Hydraulic pipe bending



      Power of Pipe Rotating Servo Motor

      W

      2000

      Power of Feeding Servo Motor

      W

      5000

      Allowable Pipe Fitting Elbow Number



      1,16(PLC)
      2,33(industrial PC)

      Storable Component Number



      1,1000(PLC)
      2,2000000(industrial PC)

      Oil Hydraulic Motor Power

      Kw

      22

      Maximum System Pressure

      Mpa

      14

      Machine Size

      cm

      6630*1860*1265

      Machine Weight

      Kg

      12000

      1.Introduction
      The product is controlled by PLC and hydraulically driven. The display operating system is touch-type full Chinese menu. It has prefabrication with various bending angles, Chinese subtitle display and man-machine dialogue operation. It can choose manual, semi-automatic and fully automatic operation modes. The mobile foot switch has both start and stop functions.
      Hydraulic system, control system, drive system, display system, etc. all adopt high-reliability imported parts, with high precision, high efficiency, suitable for mass production, with international and domestic advanced level.
      It is a CNC automatic pipe bending machine, which is equipped with a full-featured device for bending three-dimensional space pipe fittings. The input program is automatically completed during the entire bending process. The machine has the characteristics of convenient operation, stable performance, high work efficiency and high safety factor. It is an ideal equipment for the pipe fitting processing industry.

      Applications:
      1. Exhaust pipe of car, motorcycle, airplane and other machinery.
      2. Tubes of air conditioning, furnitures, bikes, outside street light, sports facilities
      3. Pipes of  kitchen and bathing facilities, pipes of medical equipments.
      4. Metal sheets of interior finishing, constructing facilities, outside protective equipments.
      ......
      Company Details
      Professional: 10 years into machinery.
      Brand: RUNTAI, China Famous Brand
      Engineers: 9 professional and experienced engineers
      Certificates: CE, ISO9001:2008
      Letters patents: 12 official patents
      Examining report: 5 official examining reports
      Innovation project: 2 innovative program awards
      Exported Countries: South Africa, India, Australia, Russia, UK, Mexico, Ukraine etc

      Trade information:
      FOB Ningbo, FOB Shanghai, CIF your port
      Payment Terms: T/T, L/C, Western Union, MoneyGram
      Delivery Terms: 30% deposit, 70% paid before shipment.
      Delivery Time: 30days after receiving deposit
      Minimum Order Quantity: 1 set
      Warranty: 1 year
      Package Details: wooden box
      Supply Ability: 30 Sets per Month
      If you have any interest or questions about the above machine, please feel free to contact with our guys:
