• Model NO.：WGJ-07
• Type：Cnc Bending Machine
• Active Roller Speed：0-4.3m,Min
• Total Power：18.5kw
• Hydraulic System Pressure：25MPa
• Top Roll Advancing Speed：1-13mm,S
• Transport Package：Wooden Box
• Specification：2500*2000*1850mm
• Trademark：Zhongtuo
• Origin：China
• Production Capacity：100pieces,Mouth

Basic Info.

Model NO. WGJ-07 Type Cnc Bending Machine Active Roller Speed 0-4.3m/Min Total Power 18.5kw Hydraulic System Pressure 25MPa Top Roll Advancing Speed 1-13mm/S Transport Package Wooden Box Specification 2500*2000*1850mm Trademark Zhongtuo Origin China Production Capacity 100pieces/Mouth

Product Description

U-Type Bracket Arc Bending Machine Metal Plate Bending Machine

 Feature:
1 reasonable structure, simple operation.
2 hydraulic drive, a molding.
3 workers labor intensity greatly reduced, safe operation.
4 intentions to innovation, competition can develop


 Description:
WGJ-U steel bending machine on the old U-shaped steel arch can be repaired, molding reuse, to overcome the existence of a series of defects in the repair, with high repair efficiency, the loss of U-shaped steel strength, high precision, and then after molding , Without skirt and other advantages.

 Parameters:

project	unit	U25U29/U36 Roll forming cold bending
Hydraulic system pressure	MPa	25
Top roll advancing speed	mm/s	1-13
Minimum bending radius	m	1.1
Active roller speed	m/min	0-4.3
Total power	KW	18.5
Total Weight	KG	3800
Dimensions	mm	2500*2000*1850

hydraulic u - steel bending machine Note
1. The equipment is mounted on a hard foundation and is positioned so that the feed rail surface is at the horizontal position.
2. I-beam must work on a horizontal table (with a rolling table).
3. Before use must be fueled (reducer plus 30 # oil, fuel tank plus 46 # hydraulic oil, after the regular replacement of new oil.
