W11S-40X3200 Universal Type Steel Plate Rolling and Bending Machine
Shaanxi HAVEN Equipment Co., Ltd.- Waterproof Rating：IPX-1
- Warranty：1-year
- Condition：New
- Certification：ISO 9001:2000, CE
- Automation：Semi-Automatic
- Suitable for：Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Base Info
- Model NO.：W11S-40x3200
- Type：Roller-Bending Machine
- Top Roller：Can up and Down
- Application：Machinery & Hardware, Textiles, Chemical
- Type for Fold-bending Machine：Hydraulic Fold-bend Machine
- max rolling thickness：40mm
- max rolling width：3200mm
- main electrical components：Siemens brand
- main motor：China famous brand
- roller material：top roller : 42CrMo, bottom roller : 45# steel
- machine color and voltage：as per client demand
- Transport Package：Steel Pallet
- Specification：W11S-40X3200
- Trademark：HAVEN
- Origin：China
- HS Code：84622990
- Production Capacity：30 Units,Month
Description
ModelMax. thickness(mm) Width Workpiece min dia Top
roller Bottom
roller Distance bottom roller Motor (KW) normal Pre (mm) mm (mm) (mm) (mm) Main Hydraulic Movement W11S-6x2000 6 4 2000 480 195 125 160 3 1.5 0.75 W11S-6x2500 6 4 2500 580 235 135 180 4 2.2 0.75 W11S-8x2000 8 6 2000 550 220 125 180 4 2.2 0.75 W11S-10x2000 10 8 2000 630 250 145 200 5.5 4 1.1 W11S-10x3200 10 8 3200 630 280 180 250 7.5 4 1.1 W11S-10x4000 10 8 4000 800 360 200 330 18.5 7.5 4 W11S-12x2500 12 9 2500 660 265 145 200 5.5 5.5 1.5 W11S-12x4000 12 9 4000 850 380 220 360 22 7.5 5.5 W11S-16x2000 16 12 2000 700 300 150 245 11 7.5 4 W11S-16x2500 16 12 2500 750 330 165 270 11 7.5 4 W11S-16x3200 16 12 3200 800 360 180 330 22 7.5 4 W11S-16x4000 16 12 4000 1200 490 250 400 37 11 7.5 W11S-20x2000 20 16 2000 780 340 180 330 22 7.5 4 W11S-20x2500 20 16 2500 800 360 180 330 22 7.5 4 W11S-20x3200 20 16 3200 850 380 220 360 30 11 5.5 W11S-25x2000 25 20 2000 800 360 220 360 30 11 5.5 W11S-25x2500 25 20 2500 850 380 240 360 30 11 5.5 W11S-25x3200 25 20 3200 1000 410 260 380 37 11 7.5 W11S-25x4000 25 20 4000 1200 490 250 400 37 11 7.5 W11S-30x2500 30 24 2500 1000 410 260 380 37 11 7.5 W11S-30x3200 30 24 3200 1100 440 260 400 37 11 7.5 W11S-35x2000 35 28 2000 1100 440 260 400 37 15 7.5 W11S-35x2500 35 28 2500 1150 460 275 420 37 15 11 W11S-35x3200 35 28 3200 1400 560 290 500 55 22 11 W11S-40x2500 40 32 2500 1250 500 290 460 55 18.5 11 W11S-40x3200 40 32 3200 1400 570 340 500 75 22 11 W11S-40x3200 40 32 3200 1480 590 340 610 55 22 11 W11S-40x5000 40 32 5000 1750 700 360 650 75 30 15 W11S-50x5000 50 40 5000 1980 790 420 780 90 37 15 W11S-60x3200 60 48 3200 1600 650 380 700 75 30 15 W11S-70x3200 70 56 3200 1750 710 420 780 75 37 15 W11S-80x3200 80 64 3200 1900 770 460 880 90 37 18.5
