• Model NO.：ZX-1625V
• Power Source：Electric
• Layout：Horizontal
• Model：Zx-1625va
• Working Area：1600*2500(W*L) mm
• Rated Power：11kw
• Max. Cutting Speed：1200mm,S
• No-Load Speed：1500mm,S
• Cutting Thickness：0.1-110mm (Depending on The Materials)
• Cutting Accuracy：±0.1mm
• Transmission Interface：Ethernet
• Drive System：Servo Motor, Linear Guide Rail, Rack and Pinion
• Material Fixed Mode：Vacuum Adsorption
• Format Supported：Dxf, Plt, etc
• Operation Property：Online,Offline Operation, Continuous Cutting with
• Safety Device：Infrared Sensing Device, 4 Emergency Stop Buttons,
• Power Supply：AC 110V,220V,380V, 50,60Hz, Single,Three Phase
• Weight：1000kg
• Transport Package：Plywood Case
• Specification：1600*2500
• Trademark：ZHUOXING
• Origin：China
• HS Code：8479899990
• Production Capacity：50set,Month

Technical ParameterModelZX-1625vaCutting Tools RecommendedRound/oscillating knifeWorking Area1600*2500mmRated Power11kwMax.Cutting Speed1200m/sNo-Load Speed1500m/sCutting Thickness0.1-110mm(depending on the materials)Cutting Accuracy+/-0.1mmTransmission InterfaceEthemetDrive SystemServo motor,linear guider rail,rack and pinionMaterial Fixed ModeVacuum adsortptionFormat SupportedDXF PLT,etcOperation PropertyOnline/offine operation,continuous cutting with high effciency,7*24 hours with zero downtimePower SupplyAC110V/220V/380V,50/60Hz,single/three phaseSafety DeviceInfrared sensing device ,4emergency stop buttons,intelligent anti-collision deviceDimension2200*3300mm(W*L)Weight1000kg



Features
1.Accurate

High requirement and constant emphasis on R&D leads to excellent and high accuracy. Our elaborate cutting machine reaches 0.1mm cutting tolerance.

2.Smooth & clean cutting edge

Even applied to very complex lines, irregular lines and other challenging requirement, our cutting machine can fulfill it well and the similar performance can hardly be done by laser cutting machine, die cutter or manual workers.

3.Diverse

Material -- It can cut nearly all of soft flexible materials and some hard materials.
The Cutting thickness -- 0.1mm to 55mm, even larger, according to the material and your requirement.
Function -- through cutting, kiss cutting, dot cutting, V- cutting,line folding, marking,etc.

4.Exquisite

The cutting machine is able to cut complex patterns with high precision and repeating precision.

Certificate

FAQ
Q1: Are you a factory or trading company?

A: We are a factory and we have lots of know how knowledge.

Q2: Do you accept customized products?

A: Yes.

And our personalized cutting machine is steady and reliable.

Q3: Can you provide OEM/ODM service?

A: Yes.

We have lots of OEM or ODM experience.

Q4: Where is your factory located? How can I get there?

A: Our factory is based in jinan, shandong province, China.

We can pick you up at the air station or train station.

Q5: What's the warranty policy?

A: Standard warranty is 12 month upon delivery.

Q6: Is there any after sales service?

A: We have integrated after sales service.

Besides our own experienced engineers, we also offer local after sales service through the help of our agents.
