• Model NO.：PBB1020,2.5 PBB1270,2 PBB1520,1.5
• Max Sheet Thickness：2.5mm
• Clamping bar lift：47
• Folding angle：0-135 degree
• Gross Weight：320kgs
• Transport Package：Plywood Case
• Specification：CE SGS ISO9001
• Trademark：HOTON
• Origin：China
• HS Code：8462299000
• Production Capacity：25 PCS,Month

Basic Info.

Model NO. PBB1020/2.5 PBB1270/2 PBB1520/1.5 Max Sheet Thickness 2.5mm Clamping bar lift 47 Folding angle 0-135 degree Gross Weight 320kgs Transport Package Plywood Case Specification CE SGS ISO9001 Trademark HOTON Origin China HS Code 8462299000 Production Capacity 25 PCS/Month

Product Description

PAN AND BOX FOLDING MACHINES FEATURES:
1.For formed component bending.
2.A fully welded structure, and compact high quality engineering, ensure minimum maintenance, together with simple and safe operation.
3.Have the function of air spring which can be installed inside the arm(Optional).
4.Adjustable bending angle stop with scale up to 135 °
5.With foot control. It is easy for operation and relax hands.
6.Segmented top beam tools.
SPECIFICATIONS:

MODEL	PBB1020/2.5	PBB1270/2	PBB1520/1.5
Max.working length(mm)	1020	1270	1520
Max.sheet thickness(mm)	2.5	2.0	1.5
Max.clamping bar lift(mm)	47	47	47
Folding angle	0-135°	0-135°	0-135°
Packing size(mm)	1460x620x1270	1700x710x1270	1960x710x1300
N.W./G.W.(kg)	285/320	320/360	385/456



Contact Us:

Andy Wang  TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.
