Cutting & Fold-bend Machine

Home > Product > Bending Machine

All Hydraulic Devices Position Measuring Function CNC System V-Grooving Machine

RSM Machinery Co.,Ltd.
  • After-sales Service：Online Video Support
  • Waterproof Rating：IPX-8
  • Warranty：1-year
  • Condition：New
  • Certification：CE
  • Automation：Automatic

Base Info

  • Suitable for：Stainless Steel
  • Type：Beading Machine
  • Machining Workpiece Width：1500mm
  • Machining Workpiece Length：3200mm
  • Min. Side Distance：6-8mm
  • X Axis Working Speed：70m,Min
  • Motor Power(X Axis)：5.5kw
  • Transport Package：Standard Export Wooden Box
  • Specification：5300*2350*1560mm
  • Trademark：RS
  • Origin：Shanghai, China
  • Production Capacity：5 PCS,Month

Description

Machining workpiece width1500mmMachining workpiece length3200mmThe thickness of grooving(stainless steel)0.5-5mmMin. thickness of plate0.5mmMin. side distance6-8mmX axis working speed70m/minX axis return speed80m/minY1 axis max distance1250mmY1 axis move speed20m/minY1 axis resolution0.001mmRepeat positioning accuracy±0.01mmZ axis resolution0.001mmMotor power(X axis)5.5KWMotor power(Y1,Y2,Z axis)1KW
All Hydraulic Devices Position Measuring Function CNC System V-Grooving MachineAll Hydraulic Devices Position Measuring Function CNC System V-Grooving MachineAll Hydraulic Devices Position Measuring Function CNC System V-Grooving MachineAll Hydraulic Devices Position Measuring Function CNC System V-Grooving MachineAll Hydraulic Devices Position Measuring Function CNC System V-Grooving MachineAll Hydraulic Devices Position Measuring Function CNC System V-Grooving Machine
FAQ

1.Can you do OEM service?
Yes, we can.

2.What's the MOQ?
A: 1 Set only.

3.How is warranty?
12 months from bill of loading(Spare parts and man-made damage are not included).
