CNC Stainless Steel Channel Letter Advertising Bending Machine
Perfect Laser (Wuhan) Co., Ltd.- Waterproof Rating：IPX-3
- Warranty：1-year
- Condition：New
- Certification：CE
- Automation：Automatic
- Suitable for：Aluminum, Carbon Steel, Stainless Steel
Base Info
- Model NO.：PEL-200
- Type：Roller-Bending Machine
- Bending Material：Ss, Alumnium
- Bending Thickness：Max 1.5mm
- Bending Width：160mm
- Function：Notching, Bending and Cutting
- Feed Speed：5~20 M, Min
- Application：Aluminum,Stainless Steel,Carbon Steel ,Galvanized
- Aluminum Bending Thickness：0.5-1.5 mm
- Stainless Steel Bending Thickness：0.5 -1.2mm
- Galvanize Plate Bending Thickness：0.5 -1.0 mm
- Carbon Steel Bending Thickness：0.5-1.0mm
- Transport Package：Wood Craftcase
- Specification：CE, ISO2001: 9000, TUV, SGS
- Trademark：Perfect Laser
- Origin：Hubei Wuhan
- Production Capacity：1000 Units,Month
Description
Model:
PEL-100
PEL-200
PEL-300
PEL-400
Control Type
PC Control Type For Bending Aluminum Only
PC Control Type For Bending All SS,CS,MS,Al
Auto Bending & Cutting Type
LCD Touch Screen Control Type
Bending Material:
Only used to bend Aluminum .
Can bend all kinds of Stainless Steel, Carbon Steel, Mild Steel, Galvanize Plate, Aluminum, Iron, etc.....
Max. Processed Thickness:
Aluminum:
0.5-1.5 mm
Aluminum: 0.5 - 1.5 mm
Stainless steel: 0.5 -1.0 mm(If 1.5mm, advanced type)
Carbon Steel: 0.5 - 1.2 mm
Mild Steel: 0.5-1mm
Galvanize Plate: 0.5-1.0 mm
Iron Steel: 0.5-1.0 mm
Max. Processed Width:
<180 mm
<180 mm
<180 mm
<150 mm
Voltage:
220V
Size:
1740*760*1450 mm
Weight:
400 kgs
Import File Format
PLT
Export File Format
DAT
Feed speed:
5-20 Meter / Min
Precision
0.05 mm
Remark:
1. Computer system and computer screen is not included in Price.
2. Machine only used to bend Aluminum Strip.
Computer system and Computer Screen is not included in Price.
User can use any computer to run our machine.
1. This model has the function of Automatic Cutting The Letter after finishing bending.
2. Computer system and Computer Screen is not included in Price.
1. Adopt advanced LCD Touching Screen to control.
2. No need PC system, Simple and compact, but need computer to make drawing
1) Friendly man-machine interface, simple configuration, touch-screen operation. Simply enter theprocessing of text, graphic design files, and then the machine can process them on materials automatically.
2) A unique three-dimensional process simulation technology, two-dimensional design file to be able to display three-dimensional effects, supplemented by translation, rotation, zoom and other functions, enables
full observation and monitoring of whole working process.
3) The original double-bent knife parallel bending technology to save time and greatly improve the
processing efficiency, the maximum bending angle reached 130 °.
4) High precision machining, feeding precision can reach 0.01mm, bending accuracy up to 0.4 °.
5) With precision automatic calibration function, based on the way of the processing material, self-adjusting process parameters, so that it can match with a variety of engraving machines and cutting machine, meet a variety of complex embedded process accuracy as much as possible.
6) Wide range of applications: CNC Bending machine can process 0-1.5mm strip of aluminum, galvanizedsteel, iron and other metal sheet.
7) It can work in 0.05 precision, and work together with laser engraving machine, plasma cutting machine torealize the advertisement processing
