Guillotine Type Hydraulic Metal Sheet Cutting Shearing Machine

Shanghai YingXin World Machinery Co., Ltd.

After-sales Service：Available
Automation：Automatic
Certification：CE, ISO 9001:2000, ISO 9001:2008, EPA, CS, RoHS
Condition：New
Warranty：1 Year
Guillotine：Guillotine Shearing Machine

Base Info

Model NO.：QC11Y
Cutting Thickness：4-20mm
Cutting Width：2000-6000mm
Shearing Angle：Adjustable
Control System：Estun E21s Nc System
Color：Customized
Transport Package：in Container
Specification：cutting width to 6000mm
Trademark：WORLD
Origin：China
HS Code：8462391000
Production Capacity：2000PCS,Year

Description

hydraulic press brake and cnc press brake
- hydraulic press machine

Specifications

Items	unit	QC11Y-6x2500	QC11Y-6x3200	QC11Y-6x4000
Max. cutting thickness	mm	6	6	6
Max. cutting width	mm	2500	3200	4000
Tensile strength of plate to be cut	N/mm2	450	450	450
Cutting angle	deg	0.5-1.5	0.5-1.5	0.5-1.5
Travel distance of back gauge	mm	20-550	20-550	20-600
Throat depth	mm	150	150	150
Stroke speeds	spm	16-26	12-22	10-20
Main motor	kW	7.5	7.5	7.5
Length	mm	3000	3700	4800
Width	mm	1500	1650	1650
Height	mm	2000	2050	2250

Items	unit	QC11Y-8x2500	QC11Y-8x3200	QC11Y-8x4000
Max. cutting thickness	mm	8	8	8
Max. cutting width	mm	2500	3200	4000
Tensile strength of plate to be cut	N/mm2	450	450	450
Cutting angle	deg	0.5-2	0.5-2	0.5-2
Travel distance of back gauge	mm	20-600	20-600	20-600
Throat depth	mm	150	150	150
Stroke speeds	spm	14-25	12-20	10-20
Main motor	kW	11	11	11
Length	mm	3040	3860	4800
Width	mm	1700	1700	1800
Height	mm	2150	2350	2480

Items	unit	QC11Y-10x2500	QC11Y-10x3200	QC11Y-10x4000
Max. cutting thickness	mm	10	10	10
Max. cutting width	mm	2500	3200	4000
Tensile strength of plate to be cut	N/mm2	450	450	450
Cutting angle	deg	0.5-1.5	0.5-1.5	0.5-1.5
Travel distance of back gauge	mm	20-600	20-600	20-600
Throat depth	mm	150	150	150
Stroke speeds	spm	12-20	10-20	10-18
Main motor	kW	11	15	15
Length	mm	3040	3860	4800
Width	mm	1700	1700	1800
Height	mm	2150	2350	2480

Guillotine Type Hydraulic Metal Sheet Cutting Shearing Machine

Guillotine Type Hydraulic Metal Sheet Cutting Shearing Machine
