Cutting & Fold-bend Machine

Home > Product > Knife Cutting Machine

Aoke Garment Pattern Cutting Plotter

Shanghai Xinao Technology Co., Ltd.
  • Warranty：1-year
  • Certification：CE, ISO 9001:2000
  • Condition：New
  • Control：Automatic
  • Application：Paper, Plastic, Leather, Fabric
  • Power Source：Electric

Base Info

  • Model NO.：GD0906, GD1209, GD1509
  • Transport Package：Wooden Box
  • Specification：ISO9001, 2000
  • Trademark：AOKE
  • Origin：China
  • HS Code：84411000
  • Production Capacity：80sets,Month

Description

Basic Info.

Model NO. GD0906, GD1209, GD1509 Transport Package Wooden Box Specification ISO9001, 2000 Trademark AOKE Origin China HS Code 84411000 Production Capacity 80sets/Month

Product Description

1. Dotted line cutting function: Dotted line cutting available on different materials for folding
2. Half cutting function: Half cutting available for folding on different materials
3. Drawing function: High precision drawings available
4. Support any CAD software
5. Easy to operate and long life span

Max speed: 1000mm/s
Max cutting thickness: 2mm
Min cutting diameter: 3mm
Overlapping precision: ≤ 0.1mm
Vacuum: 1.5KW
Control&driver: Step motor
Data port: ISA port
Input cushion: 32MB
Data form: HPGL /DXF
Data transfer speed: 10MB/S
Voltage: 220v± 10%50Hz
Aoke Garment Pattern Cutting Plotter
